14. NuVinci® shifting system
The Babboe Mountain not only has a strong Yamaha center motor (bottom bracket motor), but is has also
the NuVinci stepless shifting system. This combination Stepless shifting – as simple as adjusting the volume
on a radio. The revolutionary NuVinci Optimized transmission provides a perfectly relaxed ride and a smooth,
stepless progression from one ratio to another, literally with a twist of the wrist. NuVinci® technology means:
Concentrating less on operating the bike and more on what's important! For example, the traffic or the kids in
DAS ZEICHNET DIE NFINITY PRODUKTGRUPPEN AUS
front of you.
The continuously variable planetary transmission forms the foundation of the revolutionary NuVinci technology,
which can be adapted easily to meet your individual cycling needs. Whether you're waiting at a stoplight or
Stufenloses Schalten
straining against a headwind, with NuVinci Optimized components, you'll always find the ideal gear ratio.
You can change the gear ratio between your pedals and rear wheel in one continuous motion. Just twist the
controller slightly on the handlebar and the gear ratio is changed to any ratio within its range. This is easy to
do, no matter if you are freewheeling, pedaling under load or waiting at a stoplight.
ThE NUVINCI
®
N360 SYSTEM
FEATURES OF THE NFINITY GROUP SETS
ci N360 is the third
continuously variable
Stepless shifting
rom Fallbrook
es. The N360 is a
t and durable drivetrain
moothly and seamlessly
full ratio range
ps or gaps.
EN
DE KENMERKEN VAN DE NFINITY PRODUCTGROEPEN
N360 Shifter
the ratio of the N360
Traploos schakelen
matter of rotating the
. The shifter display
atio as a simple
hill for slower speeds
or faster speeds.
are no fixed gears,
atio is determined by
rt level. Ratio changes
de even while pedaling
torque.
N360 CVP
ges occur within the
hly and easily via
at are sealed for life
nance-free. The hub is
with rim, disc, or roller
d has an integrated
y freewheel that is
e.
1
86
User manual English
1
2
1
Boss
2
Größerer Übersetzungsbereich
Müheloses Schalten
als viele herkömmliche
auch unter Belastung
Boss
Schaltungen
B
Greater gear ratio range
Effortless shifting,
than many conventional
B
even under load
shifting systems
C
Using the NuVinci shifiting system
Groter versnellingsbereik
C
The smart NuVinci stepless shifting system makes gear shifting easier than
Moeiteloos schakelen,
dan vele conventionele
ever. You can peddle while shifting gears. It is a light-weight and durable
zelfs onder belasting
schakelsystemen
drivetrain that shifts smoothly and seamlessly across the full ratio range
without steps or gaps. Ratio changes occur within the hub, smoothly and
easily via internals that are sealed for life and maintenance-free.
The Shifter
Controlling the ratio of the N360 is simply a matter of rotating the shifter
grip. The shifter display indicates ratio as a simple graphic; a hill for slower
speeds and a flat for faster speeds.
Since there are no fixed gears, the exact ratio is determined by your
comfort level. Ratio changes can be made even while pedaling under high
torque.
All manuals and user guides at all-guides.com
15. Basic maintenance and care
1
A
1
A
3
3
Cleaning
• Your NuVinci N360 components are sealed and well protected
from the external environment. However, do not use water under
pressure (such as pressure washers or water jets) for cleaning to
prevent malfunctions due to water penetration.
• During the winter season, you should clean your bicycle in shorter
intervals so that winter road salt cannot cause any damage.
• Do not use aggressive cleaners.
Lubrication
• The NuVinci N360 CVP is provided with permanent lubrication
and the CVP internals are maintenance-free for the life of the
product.
• The NuVinci N360 internal freewheel mechanism is serviceable.
• Regular lubrication will extend the chain's service life.
Basic Repair Work
• Only a qualified bike dealer should perform any necessary work
on the NuVinci N360 CVP and shifter.
• Unauthorized work on your NuVinci N360 system could endanger
you and may void your warranty.
• Please contact your qualified bike dealer regarding any questions
or problem you may have.
• Wear Parts Cleaning - Shift cables, cable housing, handlebar grips,
sprockets, and bike chains are wear parts. Please check these
parts regularly and replace them as necessary.
Additional Information
• Refer to our web site for additional service information at
www.nuvinci.com
