Omgevingsomstandigheden
Bedrijfstemperatuur
Luchtvochtigheid
Maximale bedrijfshoogte boven zee
niveau
4
Bij temperaturen in het bereik van -25 tot -30 °C moet het laadstation voor het laden op bedrijfstemperatuur zijn
Mechanische specificaties
Bedrijfsomgeving
Bescherming van de behuizing
Behuizingsmateriaal
Kleur
Basis B x D (mm)
Totale afmetingen B x D x H (mm)
Gewicht ca.
1
Bij UC 600 wordt deze waarde verdubbeld
2
Bij UC 800 wordt deze waarde verdubbeld
Een UC 600 of UC 800 laadstation bestaat uit 2 schakelkasten in deze maat
5
Algemene specificaties
Laadbesturing
Lokale gebruikersinterface
Aanmelding gebruiker
Netwerkverbinding
Elektrisch veiligheidsschakeltoestel
Communicatieprotocol
Laadkabellengten
Max. kabellengte tussen laadstation
en dispenser
Laadnormen
EMC‑normen
Conformiteit
Aansluitplan
Tabel 13-1 Aansluitplan tussen laadstation en Dispenser
Type
laadstation
DC+
-F11
DC-
-F12
SICHARGE UC 100, UC 200, UC 300, UC 400, UC 600, UC 800
Bedieningshandleiding, 01/2024, A5E52455532-AD
UC 100
-25 °C ... +45 °C (op aanvraag uitbreidbaar)
UC 100
IP54, IK09 (touchscreen), IK10 (behuizing)
Behuizing - body: RAL 9006 - wit aluminium
Dak en sokkel: RAL 9017 - verkeerszwart
700 x 800
746 x 898 x 1800
929 x 1109 x 2000
1000 kg
UC 100
3.5, 6, 10 m
EN 61851‑1/23/24, ISO 15118 (DIN 70121)
EN 55016‑2‑1 & ‑3; EN 61000-4-2 & ‑3 & -4 & ‑5 & ‑6
Dispenser
1 Laadpunt
2 Laadpunten
L+
L+
L-
L-
UC 200
UC 300
5 ... 95% (niet condenserend)
2000 m
UC 200
UC 300
binnen en buiten
staal, gegalvaniseerd, gekleurd, C3
915 x 980
1400 kg
2060 kg
UC 200
UC 300
Siemens Controller
Siemens SIPLUS HMI TP700
RFID (optioneel)
Ethernet-interface of 3G en 4G
RCD type B (optioneel)
OCPP 1.6 (J‑SON)
100 m
CE‑verklaring
Kabeldiameter
16 ... 28 mm
16 ... 28 mm
Technische gegevens
13.1 Technische gegevens
UC 400
4
UC 400
5
1515 x 980
5
1526 x 1109 x 2000
1
2780 kg
UC 400
-
-
Beschrijving
gelijkspanning-eena
derig
gelijkspanning-eena
derig
2
177
