PSS(1) DIO T
Technical Details
Electrical Data
Supply Voltage
Tolerance Range
Galvanic Isolation
Polarity Protection
Connection
Outputs
Number
Potential Isolation
Status Indicator
Output Current at "1"-Signal
Total Load Capacity at +55 °C
Permitted Range
Short-Circuit Protection
Limitation of inductive switch-off
at the Load
Simultaneity
Residual Current at "0"-Signal
Output Signal Level
"0"-Signal low):
"1"-Signal (high) at 2.5 A load:
Output Switch Delay
Switch-off Pulse
Inputs
Number
Potential Isolation
Input Signal Level
"1"-Signal (high):
"0"-Signal (low):
Input Current
Input Delay
Status Indicator
6
24 V DC
20 ... 30 V DC including residual ripple
Yes (Optocoupler)
Yes
Screw-type connector, max. 2.5 mm
16
Yes (in groups of 8)
LED per output
2 A
10 A per block of 8
0 ... 2.5 A
Electronic
Approx. U
- 42 V
B
100 % to max. 10 A per block of 8
0 mA
0 V DC
U
- 1 V DC
B
50 µs
< 200 µs
16
Yes
+15 ... +30 V DC
-3 ... +5 V DC
Average 6 mA
< 1 ms
LED per input
2
(AWG 12)
