which it emerges. Never point the laser beam at
people, animals or reflective surfaces. Even brief
eye contact can lead to eye damage. Examining
the laser output aperture by use of optical instru-
ments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage. When wor-
king with a laser of class 2, observe the national
regulations on wearing eye protection.
• Do not reach into the chip ejector with your
hands. They could be injured by rotating parts.
• Do not work overhead with the saw. In this
manner you do not have sufficient control over
the power tool.
• Use appropriate detectors to determine if utility
lines are hidden in the work area or call the lo-
cal utility company for assistance. Contact with
electric lines can lead to fire and electric shock.
Damaging a gas line can lead to explosion. Pe-
netrating a water line causes property damage.
• Do not operate the power tool stationary. It is
not designed for operation with a saw table.
• Do not use high speed steel (HSS) saw blades.
Such saw blades can easily break.
• Do not saw ferrous metals. Red hot chips can
ignite the dust extraction.
• When working with the machine, always hold it
firmly with both hands and provide for a secure
stance. The power tool is guided more secure
with both hands.
• Secure the workpiece. A workpiece clamped
with clamping devices or in a vice is held more
secure than by hand.
• Always wait until the machine has come to a
complete stop before placing it down. The tool
insert can jam and lead to loss of control over
the power tool.
2. MACHINE INFORMATION
Intended use
This cordless circular saw is intended for length-
wise, crosswise and bevel cutting in wood while
keeping the baseplate resting firmly on the work-
piece. Sawing plastics or metals is not permitted.
TECHNICAL SPECIFICATIONS
Model No.
Voltage
No load speed
Saw blade size
WWW.VONROC.COM
CS501DC
20V
4000 /min
Ø150×Ø16×1.6mm
Sawing capacity 0°
Sawing capacity 45°
Weight
Sound pressure level L
PA
Sound power level L
WA
Vibration
Only use the following batteries of the VONROC PO-
WER 20V battery platform. Using any other batteries
could cause serious injury or damage the tool.
CD801AA
20V, 2Ah Lithium-Ion
CD803AA
20V, 4Ah Lithium-Ion
The following charger of the can be used to charge
these batteries.
CD802AA
Quick charger
The batteries of the VONROC POWER 20V battery
platform are interchangeable with all the VONROC
POWER 20V battery platform tools.
Vibration level
The vibration emission level stated in this instruc-
tion manual has been measured in accordance
with a standardized test given in EN60745; it may
be used to compare one tool with another and as
a preliminary assessment of exposure to vibration
when using the tool for the applications mentioned.
• Using the tool for different applications, or with
different or poorly maintained accessories, may
significantly increase the exposure level.
• The times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
1. Lock-off button
2. On/Off switch
3. Laser switch
4. Auxiliary handle
5. Laser
6. Scale for bevel angle
7. Wing bolt for bevel angle
EN
48mm
36mm
2.1 kg
75.3 dB(A), K=3dB(A)
86.3 dB(A), K=3dB(A)
3.015 m/s
K=1.5 m/s
2
2
7
