NOTE:
The keyboard has multiple snap points on the lattice side which must be pushed down firmly after the
keyboard is replaced.
4. Replace the eighteen (M2x2.5) screws that secure the keyboard assembly to the palmrest.
5. Connect the following cables:
a) keyboard cable
b) keyboard backlit cable
c) touchpad cable
d) touchpad button board cable
Next steps
1. Install the
system
board.
NOTE:
System board can be installed with heatsink attached.
2. Install the DC-in.
3. Install the
LED
board.
4. Install the
inner
frame.
5. Install the memory.
6. Install the
WLAN
card.
7. Install the
WWAN
card.
8. Install the
2280 SATA
SSD.
9. Install the battery.
10. Install the
base
cover.
11. Follow the procedure in
Moederbord
Removing the system board
Prerequisites
1. Follow the procedure in
2. Remove the
base
cover.
3. Remove the battery.
4. Remove the
2280 SATA
5. Remove the memory.
6. Remove the
WLAN
card.
7. Remove the
WWAN
card.
8. Remove the
inner
frame.
9. Remove the
LED
board.
10. Remove the heatsink-UMA.
11. Remove the DC-in.
About this task
The figure indicates the location of the system board and provides a visual representation of the removal procedure.
54
Demonteren en hermonteren
After working inside your
computer.
Before working inside your
SSD.
computer.
