O
PERATION
DMX Values
C
F
HANNEL
UNCTION
1
Master Dimmer
2
Contrast
3
Saturation
4
Hue
5
Sharpness
6
Color Temperature
7
Red
8
Green
9
Blue
10
Gamma
11
MAP
NovaLCTMars Software
The VIP Drive 43Nova can be configured by a computer running the NovaLCTMars software, through a
USB or ethernet connection. You can download the NovaLCTMars software from
vip-drive-43nova.
Software Setup
To install and access all functions of the NovaLCTMars software:
1.
Download the NovaLCTMars software from www.chauvetvideo.com/vip-drive-43nova.
2.
Run the setup file.
3.
After installing the application and all included drivers, connect the VIP Drive 43Nova and run the
software.
4.
Click User (U) in the menu running across the top of the window to open the drop-down menu.
5.
Click Advanced User Login (A).
6.
Type admin into the password field, and press the Login button on the screen, or press the Enter
key.
Connect the VIP Drive 43Nova to the computer before running NovaLCTMars.
Screen Configuration
The NovaLCTMars software has many configuration settings for any panel assembly connected to the VIP
Drive 43Nova. The options are divided into 3 tabs that appear on a window after clicking Screen
Configuration, selecting the product under Current Operation Communication Port, and clicking the
Next button.
Sending Card Tab
On the Sending Card tab, the resolution and refresh rate can be set. From this tab the product's
redundancy can be set, system configurations can be saved, and the product can also be restored to
factory default settings.
Receiving Card Tab
On the Receiving Card tab, the parameters sent to the software the last time this tab was viewed will be
displayed. This tab displays many options that can be edited, but Chauvet does NOT recommend altering
any of them. From this tab the firmware for connected video panels can be uploaded and downloaded.
Screen Connection Tab
On the Screen Connection Tab, there are three options for configuring the size of the connected panel
assembly, the distribution between video output ports, and the data flow: Simple, Standard, and Complex.
•
Simple Screen mode functions the same way the
•
Standard Screen mode allows the data flow and port distribution to be programmed manually with
a visual interface.
•
Complex Screen mode allows the configuration to be entered in a flow chart by driver number, port,
and panel number, as well as dimensions and offset coordinates in pixels.
VIP Drive 43Nova User Manual Rev. 2
V
P
/S
ALUE
ERCENT
ETTING
000
255 0–100%
000
255 Contrast, low to high
000
255 Saturation, low to high
000
255 -180°–180°
000
255 0–24
000
255 1000K–9500K
000
255 0–100%
000
255 0–100%
000
255 0–100%
000
255 1.0–4.0
000
127
MAP Function
128
255 MAP function active
Screen Settings
inactive
www.chauvetvideo.com/
do in the menu.
