1-3 Electrical Specifications
Accuracy is ±(% reading + number of digits) at 23°C ± 5°C
< 80%RH.
Temperature coefficient :
0.2 x (Specified accuracy) / °C, < 18°C, > 28°C .
Voltage
Function
Range
60.00V
DCV
600.0V
60.00V
ACV
600.0V
Overload protection : 1000Vrms
Input impedance : 3MΩ // less100pF
AC Conversion Type :
AC/DC Coupled True RMS responding
AC+DC Vrms accuracy :
same as ACV spec. +1% rdg. + 5dgt.
Current
Function
Range
DCA
600.0A
ACA
600.0A
±(2.5% + 5 dgt ) 66 Hz ~ 400 Hz
Overload protection : 600Arms
Position Error : ±1% of reading.
AC Conversion Type:
AC / DC Coupled True RMS responding
AC+DC Arms accuracy :
same as ACA spec. +1.5% rdg. +5dgt.
- DCA affected by the temperature and the residual
magnetism. Press HOLD key >2sec to compensate it.
Peak Hold : Peak Max / Peak Min
Function
Range
85.0V
ACV
1400V
85.0A
ACA
850A
51
Accuracy
±(0.7%+ 5 dgt)
±(1.0% + 5 dgt)
45 Hz ~ 500 Hz
Accuracy
±(1.5%+ 5 dgt )
±(1.5% + 5 dgt ) 45 Hz ~ 65 Hz
Accuracy
±(3% + 15 dgt)
±(3% + 15 dgt)
(corrected DCA Zero)
