2997640
Wire cross sectional area
H05RN-F 3X1.0 mm
Connection cable length
30 cm
Dimmable
No
Colour temperature
4000 K
Max. luminous flux
1650 lm
Housing Material
Aluminum
Motion sensor type
Microwave sensor
Motion sensor detection angle
160°
Motion sensor detection
max. 10 m
distance
Light sensor switching
Switch on: ≤50 lx
threshold (for night mode)
Switch off: >50 lx
Frequency
5.725 - 5.875 GHz
Transmission distance
max. 10 m
Transmission power
0.2 - 0.5 mW
Operating temperature
-20 to +45 °C
Storage temperature
-20 to +45 °C
Dimensions
149 x 111 x 36.5 mm
(W x H x D)
Weight
430 g
2997642
Ingress protection
IP65
Mounting height
max. 3 m
(for effective motion sensor
operation)
Input voltage
220 – 240 V/AC
Input frequency
50 / 60 Hz
Power consumption
30 W
Wire cross sectional area
H05RN-F 3X1.0 mm
Connection cable length
30 cm
Dimmable
No
Colour temperature
4000 K
Max. luminous flux
4950 lm
Housing Material
Aluminum
Motion sensor type
Microwave sensor
Motion sensor detection angle
160°
Motion sensor detection
max. 10 m
distance
Light sensor switching
Switch on: ≤50 lx
threshold (for night mode)
Switch off: >50 lx
Frequency
5.725 - 5.875 GHz
Transmission distance
max. 10 m
Transmission power
0.2 - 0.5 mW
Operating temperature
-20 to +45 °C
Storage temperature
-20 to +45 °C
Dimensions
197 x 160 x 34.5 mm
(W x H x D)
Weight
560 g
12.2 Remote control
Battery ............................................ 1x CR2025
12.3 Inline cable joiner
Rating ............................................ 250 V/AC; 16 A
Ingress protection .......................... IP65
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication reflects the technical status at the time of printing.
Copyright by Conrad Electronic SE.
*2997640 2997642 2997641 2997643_V1_0324_dm_mh_en 45035997490804747-2 I6/O1 en
6
2997641
2
2
H05RN-F 3X1.0 mm
30 cm
No
4000 K
8200 lm
Aluminum
Microwave sensor
160°
max. 10 m
Switch on: ≤50 lx
Switch off: >50 lx
5.725 - 5.875 GHz
max. 10 m
0.2 - 0.5 mW
-20 to +45 °C
-20 to +45 °C
223 x 181.5 x 36.5 mm
820 g
2997643
IP65
max. 3 m
(for effective motion sensor
operation)
220 – 240 V/AC
50 / 60 Hz
100 W
2
2
H05RN-F 3X1.0 mm
30 cm
No
4000 K
16500 lm
Aluminum
Microwave sensor
160°
max. 10 m
Switch on: ≤50 lx
Switch off: >50 lx
5.725 - 5.875 GHz
max. 10 m
0.2 - 0.5 mW
-20 to +45 °C
-20 to +45 °C
276.5 x 204 x 36.5 mm
1170 g
