Do not place anything on top of the ice dispenser or in front of the louver.
The recommended operating ambient temperature is within 1°C to 40°C. But this ice dispenser
is capable of operating at 43°C. Water connection is cold water only. Operation of the ice
dispenser, for extended periods, outside of these normal temperature ranges may affect
production capacity.
Allow the clearance specified below for proper air circulation
and ease of maintenance and/or service should they be
required.
In some high humidity environments, condensation may form inside the machine and drip onto
the floor. Do not install where the floor can be affected by water.
5. INSTALLATION
Incorrect installation can cause harm to people, animals or other items, for which the
manufacturer cannot be held responsible.
* Place the ice dispenser in the selected permanent location.
* Adjust the four legs on the bottom (adjustable up to 4.5 cm) to have the ice dispenser perfectly horizontal. Use a spirit level.
* Secure the ice dispenser to the wall by using the braces (accessories) and mounting screws (not supplied). Bend the braces
according to the installation condition.
Adjustable Leg
DIM-30DE-1
NOTICE
IMPORTANT
CAUTION
Adjustable Leg
DIM-30DE-2
5
ENGLISH
Top
Side View
20cm
Front
ICE
DISPENSER
Brace
Mounting Screw
Rear
10cm
Machine
Screw (M4)
