01 CHECKING THE COMPONENTS
Soundbar Main Unit
1
Power Cord (Subwoofer)
2
AC Plug
(Depending on the country and
model)
x 2
Holder-Screw
Wireless Surround Speaker SET (SWA-8500)
STANDBY
LINK
Wireless Receiver Module
• For more information about the power supply and power consumption, refer to the label attached
to the product. (Label: Bottom of the Soundbar Main Unit)
• The appearance of the accessories may differ slightly from the illustrations above.
• The power components are labelled (1, 2, 3). For more information about power connections,
see page 6.
Subwoofer
3
AC/DC Adapter
(Main Unit)
x 2
Screw
x 2
Surround Speaker
ENG - 2
PAIR
SOUND
MODE
VOL
WOOFER
SOUNDBAR
Remote Control /
Batteries
Wall Mount Guide
Connect the AC plug to the adapter until you hear
a "snapping" sound to ensure they are securely
fastened.
Do not detach the AC plug from the adapter (it will
not be removed once it has been attached).
Bracket-Wall Mount L
x 2
Speaker Cable
Optical Cable
Bracket-Wall Mount R
Power Cord
