IV. OPERATION
NOTE:
Be aware that this tool is always in
an operating condition, since it
does not have to be plugged into
an electrical outlet.
Power switch operation
1
CAUTION:
• Before inserting the battery pack
into the tool, always make sure that
the power switch operates properly
and returns to the "OFF" position
when the rear of the power switch
is depressed.
• Power switch can be locked in "ON"
position. Stay alert when locking
tool in "ON" position and grasp the
tool firmly using support handle and
grip.
To start the tool, press and slide the
power switch toward the "ON" position.
For continuous operation, press the
front of the power switch to lock it.
To stop the tool, press the rear of the
power switch, then slide it toward the
"OFF" position.
WARNING:
• It should never be necessary to
force the tool. The weight of the
tool applies adequate pressure.
Forcing and excessive pressure
could cause dangerous grinding
disc breakage.
• ALWAYS replace grinding disc if
tool is dropped while grinding.
• NEVER bang or hit grinding disc.
• Avoid bouncing and snagging the
grinding disc, especially when work-
ing corners, sharp edges etc. This
can cause loss of control and kick-
back.
Visual inspection and workout
test on disc
1. Always make sure that the disc has
1. Power switch
2. Always give workout test on the
3. Always make sure the disc is firmly
Grinding operation
- 11 -
CAUTION:
• After operation, always switch off
the tool and wait until the wheel has
come to a complete stop before
putting the tool down.
no cracks before use.
blade as follows.
fixed.
Brand new disc
Before use on
current disc
B
ALWAYS hold the tool firmly with one
hand on grip and the other on the side
handle. Turn on the tool on and then
apply the wheel or disc to the work-
piece.
In general, keep the edge of the
wheel or grinding disc at an angle of
about 15 degrees to the workpiece
surface.
When using a new grinding disc, do
not work the grinder in the B direction
or it will cut into the workpiece. Once
the edge of the grinding disc has been
rounded off by use, the grinding disc
may be worked in both A and B direc-
tion.
Work out time
more than 3 min.
more than 1 min.
A
