Mounting on pedestals
1.
Lay the device down on a steady soft surface
(Figure 7, pos. 4).
2.
Place the pedestals (Figure 7, pos. 3) on both
sides of the main body (Figure 7, pos. 5).
3.
Screw and tighten the pedestals with a small
screw (Figure 7, pos. 1) using a Phillips
screwdriver (Figure 7, pos. 2).
4.
Place the device on a horizontal, solid and
non-flammable surface.
5.
Place the device with a minimum clearance
distance (Figure 8) of:
•
100 cm on the top side;
•
50 cm on the sides;
•
30 cm on the back side;
•
50 cm on the front side.
6.
Do not place the device immediately below a
socket outlet.
Wall mounting
WARNING
The wall used for mounting must be made from non-flammable material and
should be able to withstand a minimum temperature of 200 °C.
CAUTION
Make sure to use suitable fastening materials, depending on the surface.
Never block the space between the device and the wall.
Figure 7
Figure 8
29
