Changing keypad parameters
Any change performed in the definition of the keypad parameters also requires
updating the keypad. This is performed by pressing the
panel will then send an update to the keypad.
Technical Specification
Electrical
Battery Type
Current Consumption
Power Output
Frequency
Modulation Type
Typical Battery Life
Low battery indication
Proximity RF frequency
Physical
Dimension (HxWxD)
Weight (Including batteries)
Environmental
Operating temperature
Storage temperature
Humidity Range
Standard Compliance
Certification body
05/2024
CR123, 3V Lithium battery (x 4)
Standby current 30µA, Max current 150 mA
869.525MHz, 10 mW
869.525MHz, 916 MHz
GFSK
3 years
2.6 V
13.56 MHz
180 x 115 x 35 mm (7.1 x 4.5 x 1.4")
0.435 kg
-10°C to 55°C (14°F to 131°F)
-20°C to 60°C (-4°F to 140°F)
Average relative humidity: 75%
EN 50131-1, EN 50131-3 Grade 2,
Environmental Class II, EN 50131-6 Type C,
EN 50131-5-3, PD6662:2017
Applica Test & Certification
Page 11
key for 2 seconds. The
5IN3045 D
