Introduction
The 2-Way WL Panda for LightSYS Air/LightSYS Plus keypad is used to remotely
program and operate the LightSYS Air/LightSYS Plus control panel. Being bi-
directional, the 2-Way keypad receives a reply status indication from the panel for each
command sent to the panel. You can operate the keypad either using a code or a
proximity tag.
Main Features
•
Bi-directional Wireless Communication
•
Full Wireless Engineer Programming
•
Up to 2 WL Panda LightSYS Plus Keypads per WL Video Expander /
Up to 8 WL Panda LightSYS Air Keypads
•
S.O.S / Two-way communication emergency key
•
Proximity tag operation
•
Double tamper protection (Box & Wall)
•
Battery economy mode
Communication Setup
Note: For LightSYS Plus communication setup, use the RP432EWV WL receiver.
The WL Panda for LightSYS Air/LightSYS Plus keypad must identify itself to the system
receiver. This can be done by typing the 11-digit serial number of the keypad into the system
or using RF mode.
To set up the keypad using the serial number refer to the security system installation
manual.
Setup using RF communication:
1.
Set the receiver to Learn Mode.
2.
Send a Write message by pressing both keys
least 2 seconds. In a voice supported system, the keypad will sound a
confirmation beep and the system will beep to acknowledge.
3.
If required to change the keypad's default settings, configure the keypad's
parameters according to the system installation manual.
05/2024
Page 13
simultaneously for at
5IN3045 D
