Grind programme
3.1 Weight
3.2 No. of cups
3.3 Manual
table 2
empty.
• T he bean container can be removed from the
machine for cleaning. To do this, press and hold the
button at the bottom edge of the bean container
in the open position . At the same time, turn the
bean container anti-clockwise until it stops and remove
it from the machine. Remove coffee residues from
the bean container with a soft, damp cloth
• T he outer grinder ring can be removed to clean
the grinding mechanism. To do this, lift the clamp
upwards and unlock the grinder ring by turning it
anticlockwise. Remove the grinder ring .
• C lean the grinding mechanism with the supplied
brush . Remaining coffee residues can be shaken
out or removed using a vacuum cleaner.
• R eplace the grinder ring in the appliance and turn it
clockwise until it locks into place . It is completely
locked when the grinder ring can no longer be
pulled up and out.
• G round coffee residues on the ground coffee chute
and on the housing can be removed with the enclosed
brush and/or a soft, damp cloth
• T o insert the bean container, place it on the appliance
and turn clockwise until it clicks into place. In this
position, the markings on the housing and on the
bean container are vertically one above the
other
. The coffee grinder can only be used if the
bean container is correctly inserted.
• T he collecting container, stainless steel plate and lid
of the bean container can be cleaned with a damp
cloth.
• N ever clean the coffee grinder and its removable
parts in the dishwasher.
6. Technical information
• T he appliance has an overload protection for the
grinding mechanism, this protects against damage by
foreign objects. If you hear a loud, rattling, previous-
ly unknown noise during the grinding process, press
the
button and clean the grinding mechanism
as described under point 5 "Cleaning and care".
• W hen the appliance is not in use it switches off
after 5 minutes. The last settings are saved auto-
matically. The appliance can be switched on again by
pressing any button.
Preparation
Grind level
method
Pour Over
6 - 26
Cold Brew
6 - 26
Filter coffee
6 - 26
French Press
27 - 39
Espresso
.
Grind quantity
50 bis 60 g
100 g
6 to 8 g
8 g
Full portafilter
1 - 5
7. Error messages in display
The bean container is empty. The quantity
in the container was less than the grind
quantity set. Fill the bean container and press
E01
the select button. This will cancel the error
message. By pressing the
grinding process continues and the remaining
grind quantity is added.
The bean container is not inserted correctly.
E02
Insert the bean container into the appliance
as described in point 5.
The motor has overheated due to being used
too much in a short time. To prevent further
damage to the appliance, the motor must
60
cool down for 60 minutes. The remaining
cooling time is shown in the display. Do not
disconnect the mains plug.
If T also appears in the display, press the Tare
button to tare the scale. If the T is still
T
visible, the collecting container is not in the
correct position.
table 3
8. Notes on disposal
• Appliances marked with this symbol
to the European Directive for WEEE (Waste Elec-
trical and Electronic Equipment).
• E lectrical appliances should not be disposed of
with household waste. Dispose of the device in an
environmentally friendly manner using appropriate
disposal systems.
• P ackaging materials are raw materials and are recy-
clable. Please recycle them.
Water quantity
1000 ml
GB
500 ml
Per cup
Per cup
25 to 40 ml
button the
are subject
10
