1.5 Attach TV Bracket
Position your TV bracket configuration (A, B, C, D, E or F) onto your TV, making sure the bracket is both centered and level over your TV hole pattern.
NOTE: The hanging tab
Secure the TV bracket using your selection:
CAUTION:
Avoid potential personal injuries and property damage! DO NOT use power tools for this step.
Tighten the screws only enough to secure the TV bracket to the TV. DO NOT overtighten the screws.
04
TV Bracket Configuration A
Illustrated (with spacers)
TV Bracket Configuration C
Illustrated (with spacers)
10
on faceplate
04
must be oriented toward the top of the TV.
H
(a)
(b)
screw/washer or
04
04
05
screw/washer/spacer.
H
a
: Flat Back
b
: Round Back / Extra Space
03
01
02
01
02
