STEP 2B Attach Wall Plate to Wall
CAUTION:
Avoid potential personal injury or property damage!
●
Mount wall plate
09
directly onto concrete surface (no wall covering)
●
Minimum solid concrete thickness: 8 in. (203 mm)
●
Minimum concrete block size: 8 x 8 x 16 in. (203 x 203 x 406 mm)
●
Minimum horizontal space between fasteners: 16 in. (406 mm)
1
14
08
Min.
16 in.
(406 mm)
Solid Concrete or Concrete Block Option
Concrete Installation Kit CMK1 is not included
Contact Customer Service to inquire about
the additional hardware.
2
08
3 in. (75 mm)
3/8 in.
(10 mm)
