If you are satisfied with the product, please give us a 5 stars rating on the website you bought it from. If you
are not satisfied please contact us at
TV Size
13"-83"
33cm-211cm
CAUTION
This Mount is intended for use only
with the maximum weight indicated.
Using heavier products might cause injury.
Long TV Wall Mount
For more information: barkanmounts.com
https://www.barkanmounts.com/support
TV Weight
US
EU
110lbs
50kg
Tilt
Swivel
and we will solve the problem for you.
Page 1
Advertenties
Samenvatting van Inhoud voor Barkan Long TV
- Pagina 1 Page 1 Long TV Wall Mount Tilt Swivel For more information: barkanmounts.com If you are satisfied with the product, please give us a 5 stars rating on the website you bought it from. If you are not satisfied please contact us at https://www.barkanmounts.com/support...
- Pagina 2 WARNING! Barkan does not take responsibility for the installation. Disregarding the safety and assembly instructions may result in the falling of, and/ or damage to your electrical appliance. Opening the package represents your undertaking to closely read and follow the instructions. When the product is installed in public places, the people in charge in those places should make sure it is used according to the instructions.
- Pagina 3 Nehezebb termékek használata PAŽNJA! Tvrtka Barkan Mounts Ltd. nije sérülést okozhat. odgovorna za ugradnju. ATENÇÃO! A Barkan Mounts Ltd. não oferece Ne obraćanje pažnje na upozorenja o sigurnosti i garantia de instalação. O não cumprimento das ATTENTION! Barkan Mounts Ltd ne garantie sklapanju može imati za posljedicu pad i/ ili oštećenja...
- Pagina 4 C A U T I O N ! You are obligated to read the safety and assembly instructions! Disregarding them may lead to injury and to the falling of the electrical appliance. A kapcsot legalább 10 mm-rel Ankur tuleb paigaldada The anchor must be (3/8”) kell a vakolat rétege alá...
- Pagina 5 Требуйте гарантию на Vraag uw installateur om een Poproś instalatora o udzielenie установку от специалиста по garantie voor de installatie van gwarancji na instalacje монтажу. het product. produktu. Это изделие предназначено De meegeleverde hardware is Dołączony okucie nie nadaje для установки на стены/ niet geschikt voor installatie się...
-
Pagina 6: Included Parts
Page 2 Included Parts not to scale TV Plate Bracket Adaptor Drilling Template inch ൗ 3 4 ൗ 5 8 1 ൗ 3 4 Required Tools 7/16” 11 mm 1/4” 6 mm 3/8” 5/32” 10 mm 4 mm No. 2+3... - Pagina 7 Page 3 Connect the TV plate to the back of the TV. Wrong Right Purchase Use the spacers (Z7) in order to adjust longer screws. the screws length inside the TV. Continue according to your TV mounting hole pattern. Page 4 75x75 mm up to 200X200 mm (inclusive) hole pattern.
- Pagina 8 Page 4 Hole pattern above 200x200 mm up to 600x400 mm: Disassemble the screws. connect the 4 adaptors to the TV plate, and reassemble the screws. Flat screen Curved screen PARTIAL PARTIAL TIGHTENING TIGHTENING Right Right Wrong Wrong...
- Pagina 9 Page 5 Position the Adaptors according to your TV’s hole pattern. Max. 400mm 200mm 400mm For more positioning options turn to page 11 Connect the TV Plate with the Adaptors to the TV in all 4 connection holes. NO FORCE FULL TIGHTENING Z4/Z5 Z1/Z2/Z3...
- Pagina 10 Page 6 Install the Bracket on the Wall. Measure the distance between the location of the TV’s mounting holes’ center and the bottom of the TV, in order to set the required height of the TV. 4.8” / 12.3cm HORIZONTAL CENTER LINE https://www.barkanmounts.com/faq 4.8”...
- Pagina 11 Page 7 Make sure all holes are drilled First use 1/4” \ 6mm drill bit. inside the studs. 1/4” \ 6mm 2.75” \ 70mm Afterwards use 3/8” \ 10mm drill bit. 3/8” \ 10mm 2.75” \ 70mm Drill with 5/32” \ 4mm drill bit. 5/32”...
- Pagina 12 Page 8 Weight test Apply force on the upper part of the Bracket and make sure it is well connected. 110Lbs/ 50Kg Place two nuts (Z8) in the nut-housing (P2). Assemble the nut-housing (P2) make sure that the tab is inserted into the slot.
- Pagina 13 Page 9 Assemble part (P3) on the nut-housings (P2). push P3 down until the small part that looks like an upside down “T” passes the highlighted tooth. upside down T part Place the decorative plastic wings on the adaptors Connect the TV with the TV Plate to the Bracket. Make sure that the TV Plate slots are positioned properly on 2 small beams.
- Pagina 14 Page 10 Insert and tighten the screws from both sides to create friction for the tilt mechanism. Adjust the TV tilt angle carefully. Z2/Z3 FALL PROOF Place the TV cables in the Cable Management. CABLE MANAGEMENT Level the TV. SCREEN LEVELING...
- Pagina 15 Page 11...
