Connect the TV plate to the back of the TV.
Wrong
Right
Purchase
Use the spacers (Z7) in order to adjust
longer screws.
the screws length inside the TV.
Continue according to your TV mounting hole pattern.
1
1b
1a
Page 4
75x75 mm up to 200X200 mm (inclusive) hole pattern.
1a
Z4/Z5
NO FORCE
C
Z1/Z2/Z3
Z6
Z7
Optional
2
