Head (2) removal and blade cleaning - Figure B
• Check that the appliance is off and disconnect it from the power mains.
• Lift the head with force to disengage it.
• To clean the blade (6/7), use the appropriate brush supplied (10 fig. A).
• To reinsert the head, press it downwards engaging both sides.
The head plate (1) is very delicate: take care not to damage it
during cleaning. We recommend gently releasing it from the
head, blowing on it or cleaning it with soap and water. Check that
the plate is completely dry before reinserting it into the head.
Take care not to drop the head (Fig. D/E).
Replacing the blade - Figure C
• Check that the appliance is off and disconnect it from the power mains.
• Remove the head as shown in the previous paragraph.
• Gently grasp the blade (6/7) from both sides and pull upwards to
disengage it from the support (12) (not visible in the figure).
• Grasp the new blade from both sides and insert the central pin (13)
into its support (12) and push downwards firmly until it snaps into
place, paying attention to keep the blade aligned with the razor body.
• Reinsert the head (2 Fig. A).
Failure to service and clean the appliance is considered as "FAILURE
TO COMPLY WITH THE INSTRUCTIONS FOR USE", therefore, the
warranty will be automatically rendered null and void.
DISPOSAL
The product packaging is made of recyclable materials. Separate
the parts according to their type and dispose of them in
accordance with applicable laws on the environmental protection.
