flow heater and to the water outlet on the wall.
f. Open the water supply, set the continuous flow heater
lever to water flow, and turn the spout/hose left and
right. Make sure the connection is tight, and fix any leaks
before use.
g. Connect the water heater plug to the power supply.
2. With power connection below the sink (ill. 4). Important!
Please ensure that the opening in the worktop or sink is large
enough for the plug. If you are unable to fit the plug into the
hole, please contact a specialist.
a. Place the spacer ring (8) with the crown facing upwards
into the lower part of the main unit (2). Make sure that
the cable is placed in the recess provided.
b. Place the rubber sealing ring (3) underneath the spacer
ring (8). Thread the power cable and the thread of
the continuous flow heater into the hole of the rubber
sealing ring (3).
c. Insert the thread of the continuous flow heater and
the power cable through the opening provided on the
sink or worktop (4). If you are unable to fit the plug into
the hole, please contact a specialist. When you first
create the opening for attaching the fitting, make sure
that it is no larger or smaller than 4 cm. Depending on
the thickness of the countertop, the fitting can still be
attached with a diameter of 4 cm and the Aquadon plug
can be inserted through the opening.
d. From below, place the cable guide ring (5) (with the
cable recess facing upwards) onto the thread of the
main unit (2). To fix, screw in the fastening nut (6).
e. Screw the flexible hose to the thread of the continuous
flow heater and to the water outlet on the wall.
f. Open the water supply, set the continuous flow heater
lever to water flow, and turn the spout/hose left and
right. Make sure the connection is tight, and fix any leaks
before use.
g. Connect the water heater plug to the power supply.
NOTE: First connect the water. If all seals are tight, the
device can be connected to the power.
Setting the water temperature (ill. 5):
Depending on the position of the lever, you can choose
between ‚cold', ‚warm' and ‚off' ranges. If the lever is turned
down, the flow for cold water will increase; turn the lever
upwards and the flow for hot water increases. With an
increase in the flow rate in the warm water range, the water
temperature drops. If the device is operated in the hot
water range, you will see the current water temperature on
the display.
NOTE: To conserve power, there is a regulator in the unit
that ensures that electricity is only consumed during the
use of hot water. Connecting and disconnecting the device
is therefore not necessary.
CLEANING AND MAINTENANCE
Cleaning the water outlet (ill.6):
M27792_Aquadon_Flex-Head_Manual_20220914.indd 8
M27792_Aquadon_Flex-Head_Manual_20220914.indd 8
When water flow becomes less consistent or weaker, the
water outlet needs cleaning. Proceed as follows: Unscrew
the water outlet in an anti-clockwise direction and descale
or replace as necessary. Then reattach the water outlet.
Cleaning of water filter (ill. 7):
If cleaning the water outlet does not produce the desired
effect, remove the water filter at the water inlet, situated
at the bottom of the thread from the main unit (2), clean it,
and then reinstall it.
SPECIFICATIONS:
Power (kw): 3
Water pressure (Mpa): 0,04 – 0,6
Waterproofing Grade: IPX4
Rated voltage: 220 – 240V ~ 50/60 Hz
Daily electricity consumption Qelec: 0.374 kWh
Load profile: 3XS
Water heating energy efficiency nwh: 37.6%
This product complies with the European directives.
This symbol means that such electrical equipment or batteries
must not be disposed of with normal household waste. You
are legally obliged to hand in such items - free of charge - to a
public collection point or distributor-created collection point for the
recycling of electrical devices and expired bulbs and batteries within
the scope of the Electrical and Electronic Equipment Act that are
not encapsulated by or fixed into the appliance, and can be removed
or separated from the appliance non-destructively, for disposal at
the end of their service life. Use rechargeable batteries instead of
single-use batteries wherever possible. The recovery and recycling
of old appliances makes an important contribution to protecting our
environment. Improper disposal can result in toxic substances being
released into the environment, which can have harmful effects upon
people, animals and plants. Batteries with an increased pollutant
content are also marked with the following symbols: Cd = cadmium,
Hg = mercury, Pb = lead. Consumers are themselves responsible for
deleting any personal data from appliances.
Food-safe
Protection class 1
CONSIGNES DE SÉCURITÉ
• Lisez la notice avant utilisation et conservez-
la en lieu sûr pour toute référence future.
• Le robinet doit être ouvert et l'appareil
doit être raccordé à une source de courant
électrique.
• Cet appareil doit être installé en position
8
