23 STEERING
– V11 S
D
:
ISASSEMBLY
•
Remove the front brake calipers, as described in
chapter 4, section F;
•
Remove cover "A";
•
Unscrew the underlying retaining nut "B";
•
Loosen screw "C";
•
Loosen the two screws "D";
•
Raise and remove handlebars and steering head unit;
•
Unscrew nut "E";
•
Loosen retaining screw "F" between steering damper
and fork bottom;
•
Remove the fork, wheel and mud guard set.
R
:
EASSEMBLY
•
Carry out the disassembly procedures in reverse
order.
Take special care to correctly position
handlebars and steering head unit not to
damage any vehicle parts.
