1. PARTS AND COMPONENTS
Fig. 1
1. Cooking griddles
2. Lower housing
3. Control panel
3A. Power icon
3B. Searing icon
3C. Fan icon
3D. Temperature display
3E. Time display
3F. Menus
3G. Time/temperature knob
3H. Menu/Start knob
4. Griddles release buttons
5. Temperature probe compartment
6. Temperature probe
7. Axis
8. Double layer filter
9. Fan cover
10. 180º button
11. Right handle
12. Position selector
13. Drip tray
14. Upper housing
15. Handle
16. Left handle
17. Spatula
NOTE:
the graphics in this manual are schematic representations and may not exactly match the
device.
2. BEFORE USE
This appliance is packaged in a way as to protect it during transport. Take the device out
-
of its box and remove all packaging materials. You can keep the original box and other
packaging elements in a safe place. This will help you prevent damage to the device when
transporting it in the future. In case the original packaging is disposed of, make sure all
packaging materials are recycled accordingly.
44
ROCKN'GRILL BISTRO
-
Make sure all parts and components are included and in good conditions. If there is any
piece missing or in bad conditions, contact the official Cecotec Technical Support Service
immediately.
Box content
-
Grill
-
Thermoprobe probe
Spatula
-
-
Instruction manual
3. PRODUCT INSTALLATION
Griddles assembly and disassembly
Assembly
Fig. 2
Open the top and bottom griddles at an angle of 105 or 180 degrees. Then, put them (with the
B slots at both ends) on the fixed griddle bracket. Next, put the griddles on the cover and press
them down until they click into place. The griddles are now assembled.
Disassembly
Fig. 3
1. Place the appliance with the top and bottom griddles open at an angle of 105 or 180
degrees to be able to remove them.
2. Press the griddles release button (B) to release griddles (B), these will automatically pop
out. You will then be able to remove them from their bracket.
WARNING: make sure the griddles are cool before removing them. If you have just finished
using the grill, wear insulating gloves to prevent burns.
Griddle adjustment
-
Top and bottom griddles closed: the edges of the top griddle (A) and the bottom griddle (B)
are closely joined. Check figure 4 for reference.
-
When the position selector (C) is moved from the unlocked position to the locked position,
the top and bottom griddles are closed and locked. When the griddles are locked with the
position selector in the unlocked position, lift the handle (D) so that the top (A) and bottom
(B) griddles are adjusted to a distance of 10 mm. Then, move the position selector (C) from
the unlocked position/1, 2, 3, 4 to 5 successively, the top (A) and bottom (B) griddles will
gradually increase from 10 mm to 40 mm. When the position selector (C) is moved to any of
the positions 1, 2, 3, 4 or 5, it can be placed in the measurement corresponding to the right
axis. Check figure 5 for reference.
