ENGLISH
-
When cooking, adjust the position of the position selector, changing the distance between
the top (A) and bottom (B) griddles, according to the thickness of each food.
-
The top and bottom griddles open fully at an angle of 105 degrees. Move the position
selector (C) to the unlocked position, hold handle (D) and open the griddles at an angle of
105 degrees. Check figure 6 for reference.
-
When the top (B) and bottom (A) griddles are opened at 105 degrees, the bottom (A) griddle
can be replaced by a flat griddle, which can be used to make pancakes, eggs, and other
foods.
-
The top (A) and bottom (B) griddles open fully at an angle of 180 degrees. Put the position
selector to the unlocked position, hold the appliance with your left hand, press and hold
the release button of the griddles with your right hand and lift the top griddle until placing
it in horizontal position.
-
When the top and bottom griddles are opened at a 180-degree angle, both can be used as
waffle plates or flat griddles for food such as grilled steaks, pork chops, chicken, pancakes,
eggs, etc. As shown in figure 7.
4. OPERATION
Fig. 1
1. Cooking griddles: easy to assemble and disassemble, top and bottom griddles are
interchangeable, as the surface has an easy-to-clean non-stick coating (dishwasher safe).
2. Lower housing: this is the body of the appliance.
3. Control panel: it is used to switch the appliance on and off, set the temperature of both
griddles, start, and stop heating, select the different menus, display the temperature and
heating status of the griddles, and to display the heating time and countdown.
3A. Power icon
: press the power icon, the indicator light will flash.
3B. Searing icon
: use this icon in conjunction with the six function menus of burgers,
sausages, fish, chicken, vegetables, and steak; it has no separate function of its own.
3C. Fan icon
: it includes two speeds: high and low. The default start speed is high.
3D. Temperature display
the top and bottom griddles, and the operating status of the heating element.
3E. Time display
: it shows the time, countdown, preheating status and the "Add
food" (tick) reminder indicator light. The "Add food" (tick) reminder indicator light will
automatically switch off after 8 seconds of flashing; after that, preheating will start.
3F. Menus : it includes seven menus: defrost, burger, sausage, fish, chicken, vegetables, and
steak.
46
46
ROCKN'GRILL BISTRO
: it shows the set heating temperature for both
NOTE: when choosing the steak menu, the drop-down menu shows the four degrees of
doneness you can choose from: med. rare, medium, med. well and well done.
3G. Time/temperature knob
: when selecting the manual mode (DIY), set and adjust
the time and temperature of the griddles.
3H. Menu/Start knob
: it is used to move through the menus and start the programme
when you have selected it.
4. Griddles release button: press the button and the griddles will come out of the upper or
lower housing.
5. Temperature probe compartment: it is used to store the temperature probe.
6. Temperature probe: it is used when grilling a steak, it detects the temperature inside the
steak to precisely control the doneness of the steak when it is placed inside it.
7. Axis: fix the right handle while adjusting the distance between the top and bottom griddles.
8. Double layer filter: it filters black smoke from the grill. It can be disassembled after use and
is dishwasher safe.
9. Fan cover: the part covering the fan forms a negative pressure zone to condense the black
smoke. It can be disassembled after use and is dishwasher safe.
10. 180° button: press the button cover, the top griddles can be opened by 180 degrees.
11. Right handle: connected to the upper housing.
12. Position selector: push the position selector to lock the top and bottom griddles; you can
also change the distance between them.
13. Drip tray: it collects grease from the griddles during grilling for easy cleaning (dishwasher
safe). It is recommended to add a small amount of water when using it to facilitate cleaning.
14. Upper housing: it has the same function as the lower housing but with the upper part,
which can be opened 180°.
15. Handle: to open and close the grill.
16. Left handle: connected to the upper housing.
17. Spatula: it is used to clean the surface of the griddles more easily.
Temperature probe
1. Use the temperature probe to get steaks with a more precise doneness and better flavour.
2. Remove the temperature probe compartment from the right side of the grill, pull it out and
insert the jack plug into the circular hole at the bottom end of the probe compartment and
make sure that it clicks into place.
3. The temperature probe is only used for grilling steaks. When the menu is set to the steak
menu, four cooking levels are displayed (med. rare, medium, med. well and well done),
corresponding to four different temperature ranges. The temperature of the top griddle
will be displayed, detected by the temperature probe. The appliance shall prioritise the
internal temperature of the food to control the cooking time of the food.
4. When inserting a temperature probe, align it with the centre of the food and insert it
halfway.
