4.
Place the cot in an upright position. Insert the support frame into the
corresponding holes in the cot frame, facing upwards on either side (fig. 5).
Make sure the metal tabs are inside the holes. Correct installation will signal
a click.
5.
Place the cot cover over the frame and then zip up (fig. 6a). Connect the
cover from below to the support frame using hook and loop fasteners (fig. 6b).
6.
Place the accessory basket in the corresponding openings of the cot frame
(fig. 7a). Make sure the metal tabs are inside the holes. Correct installation
will signal a click.
7.
Secure the basket with elastic bands, which should be hooked over the
frame projection (fig. 7b).
8.
Insert the handrail connecting tube (10, fig. A) into the cover of the opening
side of the cot (fig. 8a). Connect the tube to the frame of the cot on both
sides (fig. 8b, 8c). You will hear a click. Fasten the zip.
9.
Place the mattress in the cot (2, fig. A). The cot has been fitted correctly.
HEIGHT ADJUSTMENT
Press the height adjustment lever on both sides of the cot (fig. 9) and set the
desired height. There are 6 height levels available. It is also possible to set different
heights on either side (fig. 10).
WARNING: The maximum permissible tilt of the cot is a difference of 2 levels.
The baby's head must always be on the side in the higher position.
NOTE: Before changing the height, take the child out of the cot.
WHEEL LOCK
To lock the wheels, press in the locks located on each wheel (fig. 14a). To unlock
the wheels again, lift the wheel locks (fig. 14b).
ROCKER FUNCTION
Note! The wheels must first be locked (see: Wheel lock).
To unlock the rocker function, move the buttons on both sides of the cot towards
the outside (A, fig. 11). To lock, slide back towards the inside (B, fig. 11). Correct
unlocking and locking will be signaled by a click. The rocker function is controlled
‑ 11 ‑
