Aquatec® 900
2 Safety
2.1 Safety Information
WARNING!
Risk of Serious Injury or Damage
Improper use of this product may cause injury
or damage.
– If you are unable to understand the warnings,
cautions or instructions, contact a health care
professional or provider before attempting to
use this equipment.
– Do not use this product or any available
optional equipment without first completely
reading and understanding these instructions
and any additional instructional material such
as user manual, service manual or instruction
sheet supplied with this product or optional
equipment.
WARNING!
Risk of Falling
– Do not use if defective.
– Do not make any unauthorised alterations or
modifications to the product.
– The armrests are intended to be used on both
sides evenly. If pressure is applied on one side
only, use only half of the body weight. At
overload, there is a risk that the armrest will
break.
– If the product is used with armrest, the toilet
bowl must be securely fixed.
– Do not stand on this product.
CAUTION!
Risk of Trapping your Fingers
– When lowering the armrests, ensure that your
fingers are away from the hinges to avoid
catching them.
WARNING!
– Before first use, clean the product thoroughly.
– Before every use, check the product for damage
and ensure that it is securely assembled.
CAUTION!
Risk of Injury
Non-original or wrong parts may affect the
function and safety of the product.
– Only use original parts for the product in use.
– Due to regional differences, refer to your local
Invacare catalogue or website for available
options or contact your Invacare distributor. See
addresses at the end of this document.
2.2 Labels and Symbols on the Product
Identification Label (Fig. 9)
Manufacturer
A
UK Conformity Assessed H
B
European Conformity
C
Lot number
D
Read user manual
E
Maximum user weight
F
4
Production date
G
Unique Device
Identifier
Medical Device
I
Reference number
J
Product designation
K
The identification label is attached to the backside
of the corpus.
3 Product Overview
3.1 Intended Use
Aquatec 900 is a raised toilet seat with foldable armrests
that elevates the seating height on toilets (adjustable to: 6
cm, 10 cm or 15 cm) for a better seating position. It is fixed
with a screw system at the rear of the toilet bowl.
The product is intended to be used as an aid for self-hygiene
care and toilet purposes. The product provides support for
sitting down or standing up from a toilet.
Intended Users
Users are any adults and adolescents with limited mobility.
The user must be able to keep own balance or ensures the
availability of additional support, i.e. wall mounted grab bar.
Indications
•
Restricted or limited mobility (e.g. legs and/or hips) or
•
having balance issues to stand up or walk due to
transitional or permanent disabilities.
There are no contraindications known when using the
product as intended. For the maximum user weight of the
product, see 7.1 Technical Data (Fig. 10 – 11), page 5 .
3.2 Scope of Delivery (Fig. 1, 2)
Fig. 1a & 2a
•
User manual
•
Corpus with lid
•
Crossbar
•
Attachment cross (2x)
•
Star screw (2x)
•
Anti-slip pad (2x)
•
Screw with nut and
washer (2x)
•
Clip (2x) (Fig. 1a only)
•
Armrest (2x) (Fig. 1a
only)
4 Setup (Fig. 3 – 8)
CAUTION!
Risk of Pinching
– Take care during assembly.
1. Remove the toilet seat.
2. There are two different ways of mounting:
a) For products sold (see Figure 1a and 2a): Fix the
crossbar with anti-slip protection, screws, nut and
washer onto the toilet bowl. (Fig. 3a)
b) For products sold (see Figure 1b and 2b):
•
Phillips screwdriver
Insert the rubber dowels into the fixing holes on the
toilet bowl. Fix the crossbar with washers, anti-slip
protection, squared washers and screws onto the toilet
bowl. (Fig. 3b)
3. Choose the desired seat height and inclination from the
table in Fig. 4. The letters in Fig. 4 correlate with the
possible fixation positions in Fig. 5.
4. Place both attachment crosses in the desired fixation.
(Fig. 6)
5. Place the corpus on your toilet bowl, move it backward
and hinge the desired slot with the pin of the crossbar.
Secure the position with the two star screws. (Fig. 7)
Fig. 1b & 2b
•
User manual
•
Corpus with lid
•
Crossbar
•
Attachment cross (2x)
•
Star screw (2x)
•
Screw with washers,
anti-slip pad and rubber
dowel (2x)
•
Clip (2x) (Fig. 1b only)
•
Armrest (2x) (Fig. 1b
only)
1557428-F
