Intended use
4
Intended use
The installation kit (item no. 9100300083) enables the installation of a CoolAir
RTX1000 or RTX2000 parking cooler in a roof ventilation opening (hatch)
provided at the plant in a Scania (Highline and Topline) driver cab.
A
NOTICE!
• The parking cooler is not suitable for installation in construction machines,
agricultural machines or similar equipment. They will not work properly if
exposed to strong vibrations.
• Operating parking cooler with voltages other than those specified can
result in damage to the devices.
I
NOTE
For cabs with a mechanical ventilation hatch two holders (Scania no.
1533737), which are standard with the electrical ventilation hatch, are still
needed to fix the parking cooler.
5
Scope of delivery
CoolAir RTX1000, RTX2000 installation kit for
Scania Highline and Topline,
item no. 9100300083
Item in
Part designation
fig. 1
.
Thread insert with flange M8
3
Spacer sleeve L = 48 mm, ∅ 14 mm
$
Washer 8.5 x 20
/
Spring washer M8
1
Hex screw M8 x 65
4
Spacer sleeve L = 30 mm, ∅ 10 mm
2
Cover frame Scania
(
Washer M6
,
Allen screw with cylindrical head M6 x 45
"
2.5 m insulating tape (profile: 10 x 20 mm)
Connection cable 6 mm² x 4 m
Cable binder
1/4" hexagon bit
–
Installation manual
6
CoolAir RTX1000, RTX2000
Quantity Ref. no.
6
4445200068
6
4443900255
6
4445200113
6
4445200091
6
4445200109
4
4443900257
1
4443000428
4
4445200115
4
4445200096
1
4443300055
1
4441300250
1
4445900256
1
4445900172
1
4445102187
