Intended use
4
Intended use
The installation kit (Hi-Street/Hi-Road: item no. 9100300087, Hi-Way: item no.
9100300088) enables the installation of a CoolAir RTX1000 or RTX2000 parking
cooler in a roof ventilation opening (hatch) provided at the plant in a lveco Stralis
Hi-Street/Hi-Road (high roof) or lveco Stralis Hi-Way (high roof) driver cab.
A
NOTICE!
• The parking cooler is not suitable for installation in construction machines,
agricultural machines or similar equipment. They will not work properly if
exposed to strong vibrations.
• Operating parking cooler with voltages other than those specified can
result in damage to the devices.
5
Scope of delivery
CoolAir RTX1000, RTX2000 installation kit for
lveco Stralis Hi-Street/Hi-Road
item no. 9100300087
Item in
Part designation
fig. 1
.
Thread insert with flange M8
3
Spacer sleeve L = 18 mm, ∅ 14 mm
$
Washer 8.5 x 20
/
Spring washer M8
1
Hex screw M8 x 45
4
Cover frame Iveco
2
2.5 m insulating tape (profile: 10 x 20 mm)
(
Connection cable 6 mm² x 11 m
,
Cable binder
"
Maxi Fuse 40 A
Maxi Fuse holder (40 A)
Ring terminal 6 mm², M8
Ring terminal 6 mm², M10
Joint connector 6 mm²
Blade fuse, 2 A
Fuse holder (2 A)
Ring terminal 0.5 mm², M8
Joint connector 0.5 mm²
1/4" hexagon bit
–
Installation manual
6
CoolAir RTX1000, RTX2000
Quantity Ref. no.
12
4445200068
12
4443900236
12
4445200113
12
4445200091
12
4445200107
1
4443000433
1
4443300055
1
4441300251
1
4445900256
1
4441550010
1
4441600176
1
4441500036
1
4441500037
1
4441500038
1
4441550007
1
4441600175
2
4441500035
1
4441500034
1
4445900172
1
4445102190
