Configuration of
command input
0
IC 1
Configuration of
command input
4
IC 2
Configuration of
0
AUX 3
0
FIXED CODE
1
RADIO PROG
0
board is configured
SERIAL
ODE
in a BFT network
0
ADDRESS
1
on input-output
EXPI1
expansion board
26 -
THALIA
https://alborzsanat.com
INSTALLATION MANUAL
0
Input configured as Start E.
1
Input configured as Start I.
2
Input configured as Open.
3
Input configured as Close.
IC 1.
4
Input configured as Ped.
61
5
Input configured as Timer.
6
Input configured as Timer Pedestrian.
0
Input configured as Start E.
1
Input configured as Start I.
2
Input configured as Open.
3
Input configured as Close.
IC 2.
4
Input configured as Ped.
62
5
Input configured as Timer.
6
Input configured as Timer Pedestrian.
0
Output configured as 2nd Radio Channel.
1
Output configured as SCA (gate open light).
2
Output configured as Courtesy Light command.
3
Output configured as Zone Light command.
AUX 3 output.
4
Output configured as Stair Light
26-27
5
Output configured as Alarm
6
Output configured as Flashing light
7
Output configured as Latch
8
Output configured as Magnetic lock
Receiver is configured for operation in rolling-code mode.
0
Fixed-Code Clones are not accepted.
Fixed code
Receiver is configured for operation in fixed-code mode.
1
Fixed-Code Clones are accepted.
Disables wireless memorizing of transmitters.
0
Transmitters are memorized only using the relevant Radio menu.
IMPORTANT: Disables the automatic addition of new transmitters, clones and replays.
Enables wireless memorizing of transmitters: 1- Press in sequence the hidden key and normal
Transmitter
key (T1-T2-T3-T4) of a transmitter that has already been memorized in standard mode via the
programming
radio menu. 2- Press within 10s the hidden key and normal key (T1-T2-T3-T4) of a transmitter
1
to be memorized. The receiver exits programming mode after 10s: you can use this time
to enter other new transmitters. This mode does not require access to the control panel.
IMPORTANT: Enables the automatic addition of new transmitters, clones and replays.
Serial mode
0
Standard SLAVE: board receives and communicates commands/diagnostics/etc.
Identifies how
Standard MASTER: board sends activation commands (START, OPEN, CLOSE, PED, STOP) to other
1
boards.
connection
Address
[ ___ ]
Identifies board address from 0 to 127 in a local BFT network connection.
0
Input configured as Start E command.
1
Input configured as Start I command.
2
Input configured as Open command.
3
Input configured as Close command.
4
Input configured as Ped command.
5
Input configured as Timer command.
6
Input configured as Timer Pedestrian command.
7
Input configured as Phot (photocell) safety.
8
Input configured as Phot op safety (photocell active during opening only).
Configuration
9
Input configured as Phot cl safety (photocell active during closing only).
of EXPI1 input
10
Input configured as Bar safety (safety edge).
Input configured as Phot test safety (tested photocell).
11
Input 3 (EXPI2) on input/output expansion board is switched automatically to safety device test
1-2
input, EXPFAULT1.
Input configured as Phot op test safety (tested photocell active during opening only).
12
Input 3 (EXPI2) on input/output expansion board is switched automatically to safety device test
input, EXPFAULT1.
Input configured as Phot cl test safety (tested photocell active during closing only).
13
Input 3 (EXPI2) on input/output expansion board is switched automatically to safety device test
input, EXPFAULT1.
Input configured as Bar safety (tested safety edge).
14
Input 3 (EXPI2) on input/output expansion board is switched automatically to safety device test
input, EXPFAULT1.
