Aktive Feldverteiler AFD4 / AFD8
Produktinformation
Diese Produktinformation enthält wichtige Hinweise zu AFD4 / AFD8.
Weitere Informationen
Weitere Informationen zum Modul finden Sie in der
• Betriebsanleitung DP/PA-Koppler, Aktive Feldverteiler, DP/PA-Link und Y-Link (A5E37478168-AA).
• Handbuch SIMATIC Grundlagen Explosionsschutz (A5E00206200).
Internet:http://support.industry.siemens.com/cs/ww/de
•
Zulassung
II 3G Ex ec ic [ic] IIC T4 Gc
ATEX
II 3D Ex tc [ic] IIIC T80°C Dc
DEKRA 12ATEX0222X
IECEx
IECEx DEK 12.0069X
INMETRO
UL-BR 13.0746X
UKCA
DEKRA 21UKEX0021 X
Importer UK:
Siemens plc
Manchester M20 2UR
EAC Ex
2Ex nA ic [ic] IIC T4 Gc X
2Ex tc [ic] IIIC T80°C Dc X
CCC
GB 3836.1-2010
(Explosive atmospheres - Part 1: Equipment – General requirements)
GB 3836.4-2010
(Explosive atmospheres - Part 4: Equipment protection by intrinsic safety "i")
GB 3836.8-2014
(Explosive atmospheres - Part 8: Equipment protection by type of protection "n")
GB 12476.1-2013
(Electrical apparatus for use in the presence of combustible dust - Part 1: General requirements)
GB 12476.4-2010
(Electrical apparatus for use in the presence of combustible dust - Part 4: Protection by intrinsic safety "iD")
GB 12476.5-2013
(Electrical apparatus for use in the presence of combustible dust - Part 5: Protection by enclosures "tD")
KCC
KCC-REM-S49-DPPA
Hinweis
Der aktive Feldverteiler AFD4 / AFD8 mit den oben genannten Zulassungen kann als Busteilnehmer in der
Gerätekategorie 3G und 3D im explosionsgefährdeten Bereich der Zone 2 und Zone 22 eingesetzt werden.
An Stichleitung S1 bis S8 dürfen nur eigensichere elektrische Feldgeräte der Gerätekategorie 3G für die Zone 2 sowie
Gerätekategorie 3D für die Zone 22 angeschlossen werden.
Montieren
Explosionsgefahr
Unter Umständen entstehen bei Montage-Arbeiten zündfähige Funken oder unzulässige Oberflächentemperaturen.
Montage nie unter Explosionsbedingungen durchführen.
Vorsicht
Verletzungsgefahr durch hohes Gewicht des AFD4 / AFD8.
Das Gewicht des AFD4 beträgt 2 kg. Das Gewicht des AFD8 beträgt 3 kg. Halten Sie die Baugruppe bei der Montage
sicher in der Hand.
• Beachten Sie beim Montieren die Installations- und Errichtungsvorschriften nach EN 60079-14.
A5E03785205-AE
