Removing the Battery
To remove the rechargeable battery, press the battery re-
lease button and pull the battery out. Do not use force to do
this.
The rechargeable battery has two locking levels to prevent
the battery from falling out if the battery release button is
pressed unintentionally. The rechargeable battery is held in
place by a spring when fitted in the power tool.
Battery charge indicator
Note: Not all battery types have a battery charge indicator.
The green LEDs on the battery charge indicator indicate the
state of charge of the battery. For safety reasons, it is only
possible to check the state of charge when the power tool is
not in operation.
Press the button for the battery charge indicator or
show the state of charge. This is also possible when the bat-
tery is removed.
If no LED lights up after pressing the button for the battery
charge indicator, then the battery is defective and must be
replaced.
Battery model GBA 18V...
LED
3× continuous green light
2× continuous green light
1× continuous green light
1× flashing green light
Battery model ProCORE18V...
LED
5 × continuous green light
4 × continuous green light
3 × continuous green light
2 × continuous green light
1 × continuous green light
1 × flashing green light
Temperature-dependent overload protection
When used as intended, the power tool cannot be over-
loaded. In the event of overloading or the temperature
rising/falling outside the permitted operating temperature
range, the speed will be reduced. The power tool will not run
at full speed again until the permitted operating temperature
has been reached.
Recommendations for Optimal Handling of the
Battery
Protect the battery against moisture and water.
Bosch Power Tools
Only store the battery within a temperature range of −20 to
50 °C. Do not leave the battery in your car in the summer, for
example.
Occasionally clean the ventilation slots on the battery using a
soft brush that is clean and dry.
A significantly reduced operating time after charging indic-
ates that the battery has deteriorated and must be replaced.
Follow the instructions on correct disposal.
Assembly
Before carrying out any work on the power tool (e.g.
u
maintenance, tool change etc.), remove the battery
from the power tool. There is risk of injury from uninten-
tionally pressing the on/off switch.
to
Changing the tool (see figure A)
The drill spindle is locked when the on/off switch (11) is not
pressed. This makes it possible to change the application
tool in the drill chuck quickly, conveniently and easily.
Open the keyless chuck (2) by turning it in the direction of
rotation ➊ until the tool can be inserted. Insert the tool.
Firmly tighten the keyless chuck (2) by turning it by hand in
the direction of rotation ➋. This will automatically lock the
drill chuck.
Capacity
Dust/Chip Extraction
60–100 %
Dust from materials such as lead-containing coatings, some
30–60 %
wood types, minerals and metal can be harmful to one's
health. Touching or breathing-in the dust can cause allergic
5–30 %
reactions and/or lead to respiratory infections of the user or
0–5 %
bystanders.
Certain dust, such as oak or beech dust, is considered carci-
nogenic, especially in connection with wood-treatment ad-
ditives (chromate, wood preservative). Materials containing
asbestos may only be worked by specialists.
– Provide for good ventilation of the working place.
Capacity
– It is recommended to wear a P2 filter-class respirator.
80–100 %
Observe the relevant regulations in your country for the ma-
terials to be worked.
60–80 %
Avoid dust accumulation at the workplace. Dust can
u
40–60 %
easily ignite.
20–40 %
5–20 %
Operation
0–5 %
Starting Operation
Setting the rotational direction (see figure B)
The rotational direction switch (10) is used to change the ro-
tational direction of the power tool. However, this is not pos-
sible while the on/off switch (11) is being pressed.
Right rotation: To drill and to drive in screws, press the ro-
tational direction switch (10) through to the left stop.
Left Rotation: To loosen and unscrew screws and nuts,
press the rotational direction switch (10) through to the
right stop.
English | 17
1 609 92A A06 | (15.11.2024)
