Guaranteed Specifi cations
[Guaranteed specifi cations are measured according to EIA standard RS-490.]
Continuous Average Output Power (both channels driven, 20–20,000 Hz)
1140 watts per channel into 4 ohms
1120 watts per channel into 6 ohms
1100 watts per channel into 8 ohms
Total Harmonic Distortion (both channels driven, 20–20,000 Hz)
0.03% with 4 to 16-ohm load
Intermodulation Distortion
0.01%
Frequency Response
POWER IN:
20–20,000 Hz
(for rated continuous average output)
3 – 150,000 Hz +0, –3.0 dB
(for 1 watt output)
HIGH LEVEL INPUT:
20–20,000 Hz
(for rated continuous average output)
Damping Factor
120 (with 8-ohm load, 50 Hz)
Input Sensitivity, Input Impedance
Input
Sensitivity
For rated output
HIGH LEVEL INPUT
142 mV
BALANCED INPUT
142 mV
POWER IN
1.13 V
Output Voltage, Output Impedance
PRE OUTPUT:
1.13 V, 50 ohms
(at rated continuous average output)
Gain
HIGH LEVEL INPUT
PRE OUTPUT:
POWER IN
OUTPUT:
Tone Controls
Turnover frequency and adjustment range
BASS:
300 Hz ±10 dB (50 Hz)
TREBLE:
3 kHz ±10 dB (20 kHz)
Loudness Compensation
+6 dB (100 Hz)
Copyright
Recordings made from radio programs and other material (CDs, music
tapes, etc.) are subject to copyright regulations. Observe the applicable
laws in your country.
All manuals and user guides at all-guides.com
+0, –0.2 dB
+0, –0.2 dB
Input
impedance
For 1 W output (EIA)
14.2 mV
20 kΩ
14.2 mV
40 kΩ
113 mV
20 kΩ
18 dB
28 dB
★
Attenuator
–20 dB
Signal-to-Noise Ratio (input-converted noise)
Input
Input shorted (A weighting)
S/N ratio at rated output
HIGH LEVEL INPUT
BALANCED INPUT
POWER IN
Power Level Meters
Logarithmic compression, peak reading
meters
Output dB/% scale
Load Impedance
4–16 ohms
Stereo Headphones
Suitable impedance:
Power Requirements
AC 120 V/230 V 50/60 Hz
(Voltage as indicated on rear panel)
Power Consumption
49 watts idle
280 watts in accordance with IEC 60065
Maximum Dimensions
Width
Height 171 mm (6-3/4")
Depth 422 mm (16-5/8")
Mass
21.7 kg (47.6 lbs) net
26.0 kg (57.3 lbs) in shipping carton
Supplied Remote Commander RC-200
Remote control principle:
Infrared pulse
Power supply:
3 V DC (IEC R03 batteries × 2)
Maximum dimensions:
56 mm × 175 mm
Mass:
153 g (including batteries)
Specifi cations and design subject to change without notice for improvements.
Sonic Etiquette
Music is a great source of pleasure, but depending on the time and
circumstances, it can become an irritation for others. Keep this in mind
when setting volume levels, especially when listening at night. The use of
headphones can also be a satisfactory solution.
EIA S/N
106 dB
92 dB
91 dB
92 dB
121 dB
98 dB
8–100 ohms
465 mm (18-5/16")
×
26 mm
53
