Status
All LEDs show in sequence, followed by one (1)
LED quick-flashing yellow.
All LEDs show in sequence, followed by one (1)
LED showing constantly red.
Parallel guide
Use of the single-arm parallel guide allows precise cuts to be made along the edge of the workpiece,
or strips of even width to be cut.
The parallel guide can be fitted on either side of the base plate.
Technical data
Product properties
Product generation
Rated voltage
Weight
Saw blade diameter
Saw blade disc thickness
Kerf width
Saw blade arbor size
Rated speed under no load
Maximum cutting depth
Bevel cutting angle
Storage temperature
Ambient temperature for operation
Battery
Battery operating voltage
Weight, battery
Ambient temperature for operation
Storage temperature
Battery charging starting temperature
Noise information and vibration values
The sound pressure and vibration values given in these instructions were measured in accordance
with a standardized test and can be used to compare one power tool with another. They can also be
used for a preliminary assessment of exposure.
The data given represent the main applications of the power tool. However, if the power tool is used
for different applications, with different accessory tools, or is poorly maintained, the data can vary.
This can significantly increase exposure over the total working period.
28
Meaning
The check to ascertain the battery's state of
health did not complete. Repeat the procedure,
or consult Hilti Service.
If a connected product can still be used, the
remaining battery capacity is below 50 %.
If a connected product can no longer be used,
the battery has reached the end of its useful life
and has to be replaced. Consult Hilti Service.
SC 6WL-22
01
21.6 V
2.60 kg
(in accordance with EPTA-Procedure 01 with-
out battery)
160 mm ... 165 mm
0.5 mm ... 1.5 mm
1.5 mm ... 2 mm
20 mm
5,000 /min
60 mm
0° ... 53°
−20 ℃ ... 70 ℃
−17 ℃ ... 60 ℃
21.6 V
See the end of these operating in-
structions
−17 ℃ ... 60 ℃
−20 ℃ ... 40 ℃
−10 ℃ ... 45 ℃
2360043
*2360043*
