3.Bring the front edge of the base plate into contact with the workpiece.
Saw blade clear of the workpiece.
▶
4.Line up the marked line with the nick in the base plate (line-of-cut indicator).
5.Switch the product on.
6.Guide the saw along the cutting line at a suitable speed for it to cut smoothly through the workpiece.
Making bevel cuts (angled cuts)
Note that when bevel cuts are made, the actual cutting depth is less that the cutting depth
indicated by the scale.
1.Set the cutting angle for bevel cuts.
2.Switch the product on.
3.Guide the tool through the workpiece at a suitable speed.
Saw cuts with guide rail
1.Secure the guide rail with 2 screw clamps.
2.Set the cutting angle for bevel cuts.
3.Set the saw on the guide rail with the groove mark on the rib of the guide rail.
Use the 0° (1) groove mark for straight cuts.
▶
Use the 1°-50° (2) groove mark for bevel cuts.
▶
4.Set the cutting depth.
5.Switch the product on.
6.Advance the product along the guide rail to make the cut through the workpiece.
Care and maintenance
WARNING
Risk of injury with battery inserted !
Always remove the battery before carrying out care and maintenance tasks!
▶
Care of the product
• Carefully remove stubborn dirt.
• Carefully clean the air vents, if present, with a dry, soft brush.
• Use only a slightly damp cloth to clean the housing. Do not use cleaning agents containing silicone
as these can attack the plastic parts.
• Use a dry, clean cloth to clean the contacts of the product.
Care of the Liion batteries
• Never use a battery with clogged air vents. Clean the air vents carefully using a dry, soft brush.
• Avoid unnecessary exposure of the battery to dust and dirt. Never expose the battery to high levels
of moisture (e.g. by being dipped in water or left in the rain).
If a battery has been soaked by moisture, treat it as a damaged battery. Isolate it in a non-flammable
container and consult Hilti Service.
• Keep the battery free of extraneous oil and grease. Do not permit dust or dirt to accumulate
unnecessarily on the battery. Clean the battery with a dry, soft brush or a clean, dry cloth. Do not
use cleaning agents containing silicone as these can attack the plastic parts.
Do not touch the contacts of the battery and do not remove the factory-applied grease from the
contacts.
• Use only a slightly damp cloth to clean the housing. Do not use cleaning agents containing silicone
as these can attack the plastic parts.
Maintenance
• Check all visible parts and controls for signs of damage at regular intervals and make sure that
they all function correctly.
