KROHNE DK 32 Instructieboekje pagina 11
Verberg thumbnails
Zie ook voor DK 32:
- Handboek (56 pagina's) ,
- Technische instructies (40 pagina's) ,
- Aanvullende handleiding (28 pagina's)
Inhoudsopgave
Advertenties
NAMUR
SC2 -N0
Out put I
LED yellow output
Switch S1
Effective direction I
Switch S3
LB/LK recognition
LB : Line break
LK : Line short-circuit
Output II Power
LED green power
LED red LB/LK
Switch S2
Effective direction II
Instructieboek DK 32 - 34
Safety oriented *
SJ 2-SN and SJ 2-S1N
Output III
II
LED yellow
Relay output
LED red
LB/LK recognition
LED green
Power
* Safety-oriented isolating switching amplifiers
are only single-channel!
Output I
Power
11
