1.
General
Congratulations on your new explosion-safe AR-054 window air conditioner. If you follow the
instructions in this user manual, your new air conditioner will give you years of enjoyment.
The window air conditioning system consists of a combined outdoor unit and indoor unit with
remote control. In function the system refrigerates air. The air conditioning system provides a
continuous flow of cold fluid which decreases the temperature of the heat exchanger, which
in its turn absorbs the energy of the air, resulting in a room air temperature decrease. The
remote control enables the user to operate the indoor unit.
The part of the air conditioning system situated on the outside consists of a sheet steel
enclosure and contains a heat exchanger, a hermetically sealed compressor, one pressure
regulated valve for controlling the refrigerant and NTC temperature sensors. The sheet steel
enclosure is partly part of the protection degree against ignition applied.
The part of the air conditioning system situated on the inside consists of a heat exchanger
and NTC temperature sensors all covered by a non-metallic hood. The electronically driven
fan provides air flow on both sides of the system.
The infra-red remote control contains electronics (PCB) with a display and membrane
pushbuttons all housed in a non-metallic housing containing two (2) 1,5 V DC AAA dry cell
batteries.
The ambient temperature allowed for the apparatus is -20 °C to +45 °C.
2.
Safety Instructions
The window air conditioning series AR-054 is an explosion-safe product
suitable for use in hazardous areas with explosion hazard from flammable
gases, vapors and mist, classified as Zone 2.
This manual must be read and understood for safe use of the air conditioning split unit. All
warnings and instructions must be followed.
•
Installation must be carried out by personnel trained and qualified in explosion safety
taking the instructions mentioned on the equipment and in this manual into
consideration. Local regulations that apply to the installation must be followed.
•
Only connect this equipment to the correct voltage and mains frequency for which it is
designed. Refer to original equipment manufacturers specification or the specifications
as mentioned on the OEM's product label as attached to the unit.
•
Isolate electrical power to the air conditioning unit before electrical installation.
•
The plastic cover on the indoor side of the unit can be electrostatically charged. Only use
a damp cloth to clean the cover. Do not use solvents.
Installation manual AR-054 window air conditioning system
E
12-2024
5 / 36
