Please note: Even if it is used carefully, cutting
around foundations, stone or concrete walls, etc.
will result in the line suff ering above normal wear.
Trimming/mowing
Swing the trimmer from side to side in a scything
motion. Always keep the line spool parallel to the
ground. Check the site and decide what cutting
height you require. Guide and hold the line spool
at the required height to ensure that you cut even-
ly.
Low trimming
Hold the trimmer right in front of you at a slight
angle so that the underside of the line spool is
above the ground and the line strikes the correct
target. Always cut away from yourself. Never draw
the trimmer towards yourself.
Cutting along fences/foundations
Edge guide recommended!
When cutting approach wire mesh fences, lath
fences, natural stone walls and foundations slowly
so that you can cut close to them without striking
the obstacle with the line. If, for example, the line
strikes stones, stone walls or foundations, it will
wear or fray. If the line strikes wire fencing it will
break.
Trimming around trees
Edge guide recommended!
When trimming around tree trunks, approach
slowly so that the line does not strike the bark.
Walk around the tree, cutting from left to right. Ap-
proach grass or weeds with the tip of the line and
tilt the line spool forwards slightly. Warning: Take
extreme care during mowing work. When doing
such work keep a distance of 30 meters between
yourself and other people or animals.
Mowing
For mowing you want to cut all the vegetation
down to the ground. To do this, set the line spool
at an angle of 30° to the right. Place the handle in
the required position. Remember the increased
risk of injury to the user, watchers and animals
and the danger of damaging other items due to
objects (for example stones) being thrown out
(Fig. 17).
GB
Warning: Do not remove any objects from foot-
paths, etc. using the equipment.
The equipment is a powerful tool and can throw
small stones and other objects a distance of 15
meters or more, causing injuries and damage to
cars, houses and windows.
Sawing
The equipment is not suitable for sawing.
7. Cleaning, maintenance and
Danger!
Before putting away or cleaning the grass trimmer,
switch off and remove the battery pack.
7.1 Cleaning
•
•
•
•
7.2 Replacing the line spool
Danger! Remove the battery packs!
1. Fig. 18 Press the line spool housing together
2. Remove the empty line spool and the pressi-
3. Fig. 19 Thread the end of the line on the new
4. Press the spool cover back into the line spool
www.sidirika-nikolaidi.gr
- 27 -
ordering of spare parts
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it down with compressed air at
low pressure.
We recommend that you clean the equipment
immediately after you use it.
Clean the equipment regularly with a damp
cloth and some soft soap. Do not use cleaning
agents or solvents; these may be aggressive
to the plastic parts in the equipment. Ensure
that no water can get into the interior of the
equipment. The ingress of water into an elec-
tric tool increases the risk of an electric shock.
Use a brush to remove deposits from the sa-
fety guard.
at the points marked M and remove the spool
cover.
on spring.
line spool through the eyelet (P) in the spool
cover and allow approx. 13 cm of line to pro-
ject. Place the pression spring (N) in the line
spool.
housing.
