Set of DMX LED Spotlights
GB
Please read these operating instructions carefully
prior to operation and keep them for later refer-
ence. All operating elements and connections de -
scribed can be found on the fold-out page 3.
Contents
1
2
Safety Notes . . . . . . . . . . . . . . . . . . . . . . . 11
3
Applications . . . . . . . . . . . . . . . . . . . . . . . 11
4
Setting into Operation . . . . . . . . . . . . . . . 11
4.1 Operation with the stand . . . . . . . . . . . . . . 11
4.2 Fixed installation . . . . . . . . . . . . . . . . . . . . 12
4.3 Aligning the spotlights . . . . . . . . . . . . . . . . 12
4.4 Power supply . . . . . . . . . . . . . . . . . . . . . . . 12
5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.1.1 Colour spotlights and stroboscope . . . . 12
and running light programs . . . . . . . . . . 12
5.1.3 Music control . . . . . . . . . . . . . . . . . . . . . 13
5.1.4 Foot remote control . . . . . . . . . . . . . . . . 13
5.1.5 Master / slave mode . . . . . . . . . . . . . . . . 13
5.2 DMX control . . . . . . . . . . . . . . . . . . . . . . . 13
5.2.1 Connection . . . . . . . . . . . . . . . . . . . . . . 13
and the start address . . . . . . . . . . . . . . . 14
6
Specifications . . . . . . . . . . . . . . . . . . . . . 14
6.1 DMX functions in 15-channel mode . . . . . 15
6.2 Menu structure . . . . . . . . . . . . . . . . . . . . . 15
10
All manuals and user guides at all-guides.com
1
Operating Elements
and Connections
1 Mounting/setscrew, one for each spotlight
On the upper side of the controller, additional
threaded holes are available; if required,
remove the screws and fasten the spotlight
there.
2 Setscrews for vertical inclination of the spotlight
3 Support for the mains fuse
Always replace a blown fuse by one of the same
type.
4 Mains jack for connection to a socket (230 V~/
50 Hz) via the mains cable provided
5 Connection POWER OUT to provide an addi-
tional unit with power
6 Control SENSITIVITY to adjust the microphone
sensitivity for music-controlled light effects
7 Microphone for music-controlled light effects
8 XLR chassis plug DMX IN: DMX signal input for
connection of a light controller or connection to
the DMX signal output of another DMX-con-
trolled unit
9 XLR jack DMX OUT: DMX signal output for con-
nection to the DMX input of another DMX-con-
trolled unit
10 Connection for the remote control supplied (13)
11 Display
12 Control buttons
Button MENU to select the operating mode
Buttons UP and DOWN to change a setting
Button ENTER to call up the setting options and
to save a setting
13 Remote control with two foot switches
Switch PROGRAMS to select one of the 12
automatic light programs or one of the 7 lighting
colours
Switch BLACKOUT to switch the light off and on
