CONTROL PANEL – OVERVIEW OF BUTTONS AND CONNECTIONS
1.
Standby/On Switch: Used to turn the instrument on or off, or to activate "panel locking."
2. Master Volume Control: Adjusts the overall sound volume.
3. "Grand Piano" Button: Selects the default grand piano sound.
4. "Sound/Data + and -" Buttons: Used to adjust various parameters. Pressing both buttons
simultaneously activates the demo or teaching song.
5. Transpose Button: Activates the transpose function.
6. Metronome Button: Starts or stops the metronome.
7. Record Button: Records the music you play.
8. Play/Stop Button: Stops recording or plays back the recording afterward.
Front Left Connection:
9. Headphone Jack (1 and 2): For connecting headphones.
Rear Connections:
10. USB to Host Port: For connecting to a computer.
11. Pedal Jack: For connecting an optional three-pedal unit.
12. Sustain Pedal Jack: For connecting the included sustain pedal.
13. Audio Input: For connecting an external audio source.
14. Audio Output: For connecting the piano to an external amplification system.
15. DC Jack: For connecting the included power adapter.
Doutreligne MSP-150 Bedieningshandleiding – Manuel d'utilisation – User Manual
