Other system products approved for use with this product can be found at your local Hilti Store or online at:
www.hilti.group | USA: www.hilti.com
4
Technical data
Power supply (2 x)
Measuring range
Distance measurement accuracy
IEC 60529 protection class (dustproof and sprayproof)
Operating temperature
Recommended temperature range for transport and storage
Weight in accordance with EPTA procedure 01
Battery (2 x)
Battery life (number of measurements), up to
Laser deactivation after
Device shutdown after
5
Operation
5.1
Preparations at the workplace
5.1.1
Inserting the batteries
Make sure that battery polarity is correct. Change the batteries only as a pair. Do not use damaged
batteries.
▶ Open the battery compartment and insert the batteries.
5.1.2
Switching the product on and off
1. Short-press the ON / Delete / OFF button to switch the product on.
2. Press the ON / Delete / OFF button for 2 seconds to switch the product off.
5.1.3
Switching the acoustic signal on and off
▶ Simultaneously press the Area measurement / Units button and the ON / Delete / OFF button for 2
seconds to switch the acoustic signal on or off.
5.2
Working / Measurement reference
All measurements use the rear edge of the laser range meter as the reference point.
▶ Hold the rear edge of the laser range meter against the point from which the measurement is to be taken.
5.2.1
Taking single measurements
1. Press the ON / Delete / OFF button to activate the laser beam.
2. Aim the laser beam at the target and press the Measure / Continuous measurement button.
◁ The distance is shown in the display.
Press the ON / Delete / OFF button once to delete the last measured values.
Press the ON / Delete / OFF button again to return from area measurement to distance measure-
ment.
10
English
Printed: 29.03.2018 | Doc-Nr: PUB / 5410137 / 000 / 00
2
3
7
6
PD-S
1.5 V
0.2 m ... 60 m
±1.5 mm
IP 54
−10 ℃ ... 50 ℃
−25 ℃ ... 70 ℃
95 g
AAA
5000
90 s
180 s
2190182
