30
SCHEDULE TIMER BUTTON
This button enables or disables the schedule timer.
31
TIME ADJUST BUTTON
These buttons are used to adjust the clock or, when in
programming mode, to adjust the programmed action
time. Both buttons have an auto-repeat function.
32
TEMPERATURE ADJUST BUTTONS
These buttons are used to adjust the current setpoint
or, when in programming mode, to adjust the
programmed setpoint temperature (step = 1°C). Both
buttons are also used to adjust the day of the week.
33
OPERATION CHANGE/
This button is a multi-purpose button. Depending on
the previous manipulations of the user, it can have
following functions:
1 select the operation mode of the installation
(FAN, DRY, AUTOMATIC, COOLING, HEATING)
2 toggle between minimum temperature and
maximum temperature when in limit operation
34
SETPOINT/LIMIT BUTTON
This button toggles between setpoint, limit operation
or
(programming mode only).
35
FAN SPEED BUTTON
This button toggles between L (Low), H (High), HH
(very High),
(Automatic).
36
AIR FLOW DIRECTION ADJUST BUTTON
This button enables to adjust the air flow direction.
Operation manual
4
All manuals and user guides at all-guides.com
37
This button is used to reset the air filter cleaning time
icon.
3. Setting up the controller
After initial installation, the user can set the clock and
day of the week.
The controller is equipped with a schedule timer that
enables
automatically; setting the clock and day of the week is
required to be able to use the schedule timer.
1
Hold down the
BUTTON
read-out and the day of week indicator will blink, both
can now be adjusted.
Use the
clock. Each time pressing the time adjust button will
in/decrease the time by 1 minute. Keeping the
the time by 10 minutes.
Use the
of the week. Each time pressing the
Press the
and day of the week.
If the controller, with blinking clock and day of week
read-out, is left untouched for 5 minutes, the clock
and day of the week will return to their previous
settings; the clock setting function is no longer active.
2
To set up the schedule timer, refer to chapter 6.
"Programming the schedule timer" on page 10.
AIR FILTER CLEANING TIME ICON RESET
BUTTON
the
user
to
operate
CLOCK SETTING FUNCTION
button for 5 seconds. The clock
&
buttons to adjust the
or
button pressed will in/decrease
&
buttons to adjust the day
buttons will display the next or previous day.
button to confirm the current set time
SETTING UP THE SCHEDULE TIMER
the
installation
or
CZ-02RT11P
Remote controller
4PW15515-1
