Installation manual AR-051 air conditioning systems
Table of contents
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Artidor supplies air conditioning systems where the outdoor unit and the indoor unit are
explosion-safe, or only one of them. This manual provides information and instructions
regarding both explosion-safe units. This does not mean that this also applies to your order.
Please consult the order confirmation or the packing list of your order.
1.
General
Congratulations on your new explosion-safe AR-051 air conditioner. If you follow the
instructions in this user manual, your new air conditioner will give you years of enjoyment.
The explosion-safe AR-051 air conditioner has been designed to safely provide users with
cool and warm air in order to maintain the desired room temperature.
The air conditioning system consists of an outdoor unit and an indoor unit with remote
control. In function the system refrigerates air. The indoor unit contains a heat exchanger
which is connected to the outdoor unit using special tubing. The outdoor unit provides a
continuous flow of cold fluid which decreases the temperature of the heat exchanger, which
in its turn absorbs the energy of the air, resulting in a room air temperature decrease. The
remote control enables the user to operate the indoor unit.
The outdoor unit consists of a sheet steel enclosure and contains a heat exchanger, a
hermetically sealed compressor, one on more valves for controlling the refrigerant, an
electrically driven fan assembly, electronics PCB and NTC temperature sensors. The sheet
steel enclosure is partly part of the protection degree against ignition applied.
Installation manual AR-051 explosion-safe air conditioning systems
3
4
5
6
6
6
8
9
9
9
10
10
10-2024
3 / 44
