EN-4
4.2 Menu Structure - V22XW
4.3 Using the Instrument
Weiging application:
1.If required, place an empty container on the pan and press Tare.
2.Add sample to the pan or container. The display shows the weight of the sample.
5. MAINTENANCE
5.1 Cleaning
WARNING: Electric Shock Hazard. Disconnect the equipment from the power supply before cleaning.
Make sure that no liquid enters the interior of the instrument.
Attention: Do not use solvents, harsh chemicals, ammonia or abrasive cleaning agents.
The exterior surfaces of the instrument may be cleaned with a cloth dampened with water and a mild detergent.
5.2 Troubleshooting
For technical issues contact an Authorized Ohaus Service Agent. Please visit our website www.ohaus.com to locate the
Ohaus office nearest you.
6.TECHNICAL DATA
The technical data is valid under the following conditions:
Indoor use only
Operating temperature: -10º C (14º F) to 40º C (104º F)
Relative humidity: 10% to 90% relative humidity, non-condensing
Altitude: Up to 2000 m
Power: AC Adapter (supplied) - 12 VDC 0.84 A output, internal rechargeable sealed lead-acid battery
Mains supply voltage fluctuations: up to ± 10% of the nominal voltage
Installation Category: II
Pollution Degree: 2
Specifications:
MODEL
Capacity x Readability (Max x d)
Maximum Displayed Resolution
Repeatability (at 20° C)
Linearity (at 20° C)
7. COMPLIANCE
Compliance to the following standards is indicated by the corresponding mark on the product.
Mark
Standard
This product complies with the EU Directives 2014/30/EU (EMC), 2014/35/EU (LVD) and 2014/31/EU
(NAWI). The EU Declaration of Conformity is available online at www.ohaus.com/ce.
This product complies with the EU Directive 2002/96/EC (WEEE). Please dispose of this product in
accordance with local regulations at the collecting point specified for electrical and electronic equipment.
For disposal instructions in Europe, refer to www.ohaus.com/weee.
Menu:
C.A.L
Span
Lin
Menu
GEO
Items:
End
.
M.O.d.E
U.n.i.t
Reset
kg
Check
g
End
oz
lb
lb:oz
End
V22PWE6T
V22XWE6T
6000 g x 1 g
6000
1 g
± 1 g
E.n.d
V22PWE15T
V22XWE15T
15000 g x 2 g
7500
2 g
± 2 g
