English
Contents
• Application
• Scope of supply
• Mounting
• Specifications
Programming - Plug & Play
Programming - manual
• Programming door calls
• Programming door calls at the
handsfree bus telephone
• Programming door calls via the
storey call button
• Programming internal calls
• Dialling the door station
Wiring diagram
14
Application
The compact video set for 1 or 2 res-
idential units. Encompasses the door
station for surface mounting, line
rectifier for distributor mounting (9
TE) and bus telephones with colour
monitor for surface mounting. With
the basic functions calling, speech,
vision and door release. Simple com-
missioning using Plug & Play pro-
gramming. Additional functions such
as internal speech or dialling the
door station can be programmed.
Electrical voltage
Mounting, installation and servicing
work on electrical devices may only
be performed by a suitably qualified
electrician.
Electrostatic charging
As a result of electrostatic charging,
direct contact with the circuit board
can result in destruction of the
device. Direct contact with the circuit
board must therefore be avoided.
The following installation situa-
tions must be avoided without
fail:
• Direct ajour light
• Direct sunlight
• Extremely bright picture back-
ground
• Highly reflective walls on the
opposite side of the door station
• Lamps or direct light sources
Scope of supply SET CV 850-01
• Door station CV 850-1
• Siedle screwdriver
• Video set line rectifier VSNG 850-0
• Bus telephone BTSV 850-03 or
BFSV 850-03
• This product information
Scope of supply SET CV 850-02
as described above, but
• door station CV 850-2
• 2 bus telephones BTSV 850-03 or
BFSV 850-03
• This product information sheet
Scope of supply SET CV 850-11
• Door station CV 850-1
• Siedle screwdriver
• Video set line rectifier VSNG 850-1
• Bus telephone with colour monitor
BTSV 850-03 or BFSV 850-03
• This product information
Scope of supply SET CV 850-12
as described above, but
• door station CV 850-2
• 2 bus telephones with colour
monitor BTSV 850-03 or
BFSV 850-03
Door station mounting
1 Unscrew the front of the housing.
To do this, release the Siedle screw
on the underneath of the housing.
Hinge the front of the housing
forward.
2 Surface mounting the door sta-
tion. Recommended mounting
height appr. 1.50 m /4.9 ft. to centre
device. Please note: The cable is
inserted in the lower area of the
base plate!
3 Strip back the installation cable
close to the wall (appr. 10 mm)
and insert the cores into the base
plate. Fasten the base plate using 4
screws. Close the two openings at
the top using rubber stoppers. Install
in accordance with the terminal
diagram. The cores may only be laid
in the admissible installation space.
4 The pick-up angle of the camera
can be mechanically preadjusted on
the vertical and horizontal by appr.
30° depending on the mounting
situation. To change the pick-up
direction of the camera, it can be
positioned in the required direction.
To change the pick-up direction,
loosen the two cross-head screws
slightly. Position the camera in the
required direction. Then fix the
required position using the two
cross-head screws.
