Location of controls
1) LCD display
2) Stop
button
3) Skip down
button
4) Repeat button
5) USB playback LED indicator
6) Speaker
7) CD component
8) On-off/Playback button
9) Skip up
button
10) Program button
11) USB socket
12) Rod antenna
13) Tuning knob
14) Aux in jack
15) Battery compartment
16) Handle
17) Volume knob
18) Function selector
19) AC socket
Caution:
Usage of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation
exposure. This unit should not be adjusted or repaired by anyone except qualified service personnel.
Precautions for use
Installation
Unpack all parts and remove protective material.
Do not connect the unit to the mains before checking the main voltage and before all other connections have been made.
Do not cover any vents and make sure that there is a space of several centimeters at the back of the unit for ventilation.
AC connection
1.
Connect the one end of the detachable power cord to the AC socket (19) and the other end to the ac outlet.
2.
Turn on the unit by press and hold On-Off/Play button (8).
DC connection
For DC operation, please insert 6 pcs size c (UM-2) battery at batter compartment (15) as
below direction and please unplug the AC socket (19) during operate with battery:-
Listening to radio
Operation
1.
Turn on the unit (8) and slide function selector (18) to select Radio mode.
2.
Turn the tuning knob (13) to set the station frequency as desired.
3.
Adjust volume knob (17) to the desired volume level.
Hints for best reception:-
-
FM : the receiver has rod antenna (12) hanging at the rear cabinet. This antenna should be totally and extended for best reception.
Playing compact disc
Getting start
Slide function selector (18) to select " CD/AUX " mode,
1.
2.
Open the CD door (7).
3.
Place a CD with the printed side facing up inside the tray & then close the CD door.
4.
Focus search is performing, the LCD display (1) will show the total number of tracks & total playing time.
Play / pause mode
Press the " play/pause
1.
To interrupt, press the " play/pause
2.
to resume normal playback.
Stop mode
If " stop
" button (2) is pressed during play or pause mode, system will go to stop mode.
1.
" button (8) to start playback, the first track will start playback.
" button (8) once, and the playing time will be freeze on the LCD display (1). Press again
English - 2
