KREIOS
FRESNEL 80W RGBW
6 CHANNELS MODE
DMX CHANNEL 1
SHUTTER
DMX CHANNEL 2
DIMMER
DMX CHANNEL 3
RED
DMX CHANNEL 4
GREEN
DMX CHANNEL 5
BLUE
DMX CHANNEL 6
WHITE
"M4CH"
5 CHANNELS MODE
DMX CHANNEL 1
DIMMER
DMX CHANNEL 2
RED
DMX CHANNEL 3
GREEN
DMX CHANNEL 4
BLUE
DMX CHANNEL 5
WHITE
14
All manuals and user guides at all-guides.com
DMX
Mid Point
Function
range value
DMX value
000-009
5
Black-out
010-019
14
Open
020-029
24
Black-out
030-119
–
Strobe at variable speed from slow to fast (3.27 s – 30 ms)
120-149
–
Pulse open at variable speed from slow to fast (42.6 s – 120 ms)
150-179
–
Pulse close at variable speed from slow to fast (42.6 s – 120 ms)
180-204
192
Random Strobe
205-229
218
Full Independent Random Strobe
230-324
–
Red, Yellow, Cyan and Blue colour effects at variable speed
235-255
245
Open
000-255
–
Proportional dimmer
000-255
–
Proportional colour
000-255
–
Proportional colour
000-255
–
Proportional colour
000-255
–
Proportional colour
DMX
Mid Point
Function
range value
DMX value
000-255
–
Proportional dimmer
000-255
–
Proportional colour
000-255
–
Proportional colour
000-255
–
Proportional colour
000-255
–
Proportional colour
