KREIOS
FRESNEL 80W RGBW
"RGBW"
4 CHANNELS MODE
DMX CHANNEL 1
RED
DMX CHANNEL 2
GREEN
DMX CHANNEL 3
BLUE
DMX CHANNEL 4
WHITE
1 CHANNEL MODE
DMX CHANNEL 1
DIMMER
15 CHANNELS MODE
DMX CHANNEL 1
SHUTTER
DMX CHANNEL 2
DIMMER
DMX CHANNEL 3
DIMMER FINE
DMX CHANNEL 4
RED
DMX CHANNEL 5
RED FINE
15
All manuals and user guides at all-guides.com
DMX
Mid Point
Function
range value
DMX value
000-255
–
Proportional colour
000-255
–
Proportional colour
000-255
–
Proportional colour
000-255
–
Proportional colour
DMX range
Mid Point
Function
value
DMX value
000-255
–
Proportional dimmer
DMX
Mid Point
Function
range value
DMX value
000-009
5
Black-out
010-019
14
Open
020-029
24
Black-out
030-119
–
Strobe at variable speed from slow to fast (3.27 s – 30 ms)
120-149
–
Pulse open at variable speed from slow to fast (42.6 s – 120 ms)
150-179
–
Pulse close at variable speed from slow to fast (42.6 s – 120 ms)
180-204
192
Random Strobe
205-229
218
Full Independent Random Strobe
230-324
–
Red, Yellow, Cyan and Blue colour effects at variable speed
235-255
245
Open
000-255
–
Proportional dimmer
000-255
–
Proportional dimmer
000-255
–
Proportional colour
000-255
–
Proportional colour
