Philips SBC SC477 DECT Gebruiksaanwijzing pagina 10
Inhoudsopgave
ENGLISH
10
1 Set the MONITOR / INTERCOM power on switch (8) on the Baby Unit
2 Switch on the Parent Unit by pressing the POWER button.
LEVEL
SYSTEM
3 Wait for an established connection (system check lights green).
POWER
4 Adjust the loudspeaker volume level of the Baby Unit to a level you prefer.
5 Adjust the loudspeaker volume level of the Parent Unit to a level you
6 On the Parent Unit, press and hold the TALK button (15) and talk clearly
LEVEL
SYSTEM
POWER
7 Release the TALK button (15) when you are finished.
8 On the Baby Unit, press and hold the TALK (3) button and talk clearly
SYSTEM
9 Release the TALK (3) button when you are finished.
All manuals and user guides at all-guides.com
Two way intercom
Your SBC SC477 is suited for use as a two-way intercom.
to INTERCOM.
> The DECT system check light blinks (green).
prefer.
into the microphone.
Note: Wait with talking until the system check light is blinking green.
Note: In case the TALK button is pressed on the Parent Unit, and the
loudspeaker volume of the Baby Unit is set to 0, the system check lights
will light red.
Note: In case the TALK button is pressed on the Baby Unit, and the loudspeaker
volume of the Parent Unit is set to 0, the Parent Unit will beep to indicate
this.
into the microphone.
While the TALK button on either unit is being pressed, a signal from the
other unit cannot be heard. In other words,only one person should speak
at a time.
