Adjusting microphone sensitivity

1 Set the Single Point Control mode switch (19) on the Parent Unit to

BABY SENSITIVITY.

2 Press the Single Point Control +/- button (20) on the Parent Unit to

increase/decrease the microphone sensitivity of the Baby Unit.

> The sound-level lights (12) on the Parent Unit give visual feedback about

the setting for approximately 3 seconds.

0 lights = minimum level

5 lights = maximum level (continuous transmission)

Note: When set to maximum level (continuous transmission), the Baby Unit

monitors continuously and all sounds, regardless of level, can be heard on

the Parent Unit. Battery operating time may decrease to approximately

8 hours during continuous transmission.

Note:You can only change the Baby Unit sensitivity if the connection between

the Baby Unit and Parent Unit is established

1 Set up both units to MONITOR your baby's sounds.

2 Adjust the loudspeaker volume level of the Baby Unit, using the Single Point

Control switch and buttons, to a level you prefer.

3 On the Parent Unit, press and hold the TALK button (15) and talk clearly

LEVEL

SYSTEM

into the microphone.

While the TALK button on the Parent Unit is being pressed, no sounds from

POWER

the Baby Unit can be heard on the loudspeaker of the Parent Unit.

Note: Wait with talking until the system check light is blinking green.

Note: In case the loudspeaker volume of the Baby Unit is set to 0 the system

check light will light red, while pressing the TALK button.

4 Release the TALK button when finished.
