ORIGINAL OPERATING INSTRUCTIONS
TE 7‑C rotary hammer
It is essential that the operating instructions
are read before the power tool is operated for
the first time.
Always keep these operating instructions to-
gether with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents
1 General information
2 Description
3 Insert tools, accessories
4 Technical data
5 Safety instructions
6 Before use
7 Operation
8 Care and maintenance
9 Troubleshooting
10 Disposal
11 Manufacturer's warranty - tools
12 EC declaration of conformity (original)
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
All manuals and user guides at all-guides.com
1 These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the designation "the
power tool" always refers to the TE 7-C rotary hammer.
Operating controls and parts 1
@
;
=
Page
%
13
&
14
(
16
)
16
17
19
20
21
22
23
23
24
1.2 Explanation of the pictograms and other
Warning signs
General
warning
Chucks
Function selector switch
Control switch
Forward / reverse switch
Side handle with depth gauge
Interface for TE DRS‑M dust removal module
Supply cord
information
Warning:
electricity
en
13
